GB
THE SUBWOOFERS' OPERATING ELEMENTS (FIG. 4)
Mains connection (2)
The subwoofer is equipped with an integrated amplifier and needs to be connected
to a mains outlet by means of the supplied mains cable. The voltage selector has
been set at the factory to 230 V for operation in Europe.
Warning: Connecting the subwoofer to a 230 V mains outlet while the voltage
selector is set to 115 V will lead to immediate destruction of the amplifier!
Power switch (10)
The subwoofer is switched off in position „Off" and on in position „On". We
recommend using the „Auto" position. In this setting, the subwoofer will switch on
automatically as soon as a music signal is detected and off again approx. 15 minutes
after it no longer receives a signal. The LED (9) is red in stand-by mode and green
when the subwoofer is in operation. The plug should be disconnected from the mains
when subwoofer is not used for long periods.
Line inputs (6)
For connection to the low-level outputs of the receiver/amplifier. Ref. fig. 2 and 3.
High-level inputs (5)
For connection to the high-level (speaker) outputs of the receiver/amplifier.
Ref. fig. 1.
High-level outputs (4)
For connecting the satellites using the high-level inputs. Ref. fig. 1.
9
