b) Making a link (pairing)
• Activate Bluetooth on your mobile device.
• When the product is turned off, press and hold the O button for approx. 7 seconds until the
LED flashes red and blue in turns.
• After a short time, "SH236A" will appear in the list of available Bluetooth devices on your
device. Select "SH236A".
If you are prompted to enter a password, enter 0000.
• As soon as the connection is successfully established, the blue LED flashes twice at an
interval of 6 seconds.
When an audio signal is transferred, the blue LED flashes once at an interval of 8 seconds.
With some mobile phones it may be necessary after the pairing process to confirm
the link between your mobile phone and the product.
This is normally necessary if you already have at least one other Bluetooth device
registered to the mobile phone or if the mobile phone is connected to another device
(such as a Bluetooth headset).
The link will disconnect if the product or paired Bluetooth device is turned off
or removed from range. When the respective device is turned back on or when
the Bluetooth device comes back into range of the product, the connection is
automatically restored.
To enable this automatic reconnection, this function may need to be activated on
the Bluetooth device (please inform yourself on this point in the instructions for your
Bluetooth device).
To reset the product, press and hold the O and – buttons simultaneously for
5 seconds with the product switched on. The product is then in pairing mode (LED
flashes red and blue in turns).
If after 5 minutes no connection has been established, the product automatically
switches itself off.
c) Connecting to additional devices
• Disconnect the product from the first coupled device by deactivating Bluetooth on the first
device.
• Turn the product off and then on again.
• On your second device, connect to the product.
• Turn on Bluetooth on the first device. The product is now connected with both devices.
• If you turn on the product again at a later time, it will automatically connect with only one
device. For the second device, the connection must be made manually.
• If you are in a call on the first device and receive an incoming call on the second device,
double-click the O button to accept the call from the second device. The first call is placed
on hold.
To reject the second call, press and hold the O button for 2 seconds.
Double-click the O button to switch between the two conversations.
Some Apple devices show the charging status of the product on the display.
d) Hands-free set
Picking up a call
Ending a call
Rejecting an incoming call
Redial
Activating/deactivating mute
Switching between headset and
smartphone
e) Adjusting volume
Increase the volume
Decrease the volume
When you reach the minimum/maximum volume, an acoustic signal sounds.
f) Voice control
In standby mode, press and hold the O button for 2 seconds to activate voice control for
Android or iOS.
Briefly press the O button
Press and hold the O button for 2 seconds
Double-click the O button
Press and hold the – button for 2 seconds
Press and hold the + button for 3 seconds
Briefly press the + button
Briefly press the – button
g) Music control
Playback
Pause
Next track
Previous track

Troubleshooting

The headset does not respond to key commands, automatically stops playback or does
not turn on.
• The battery has depleted. Recharge the battery completely.
No sound.
• The volume is set to the minimum.
• The device is no longer paired. Repeat the pairing process.
• The devices are not within range (max. 10 m).
There are drop outs in playback.
• The devices are not within range (max. 10 m).
• Other devices are interfering with radio transmission. Increase the distance to such devices.

Care and cleaning

• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these may
damage the casing or cause the product to malfunction.
• Do not immerse the product in water.
• Use a dry, lint-free cloth to clean the product.
• The ear plugs can be removed to clean the earphones.

Declaration of Conformity (DOC)

Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declares that this
product conforms to Directive 2014/53/EU.
Click on the following link to read the full text of the EU Declaration of Conformity:
www.conrad.com/downloads
Select a language by clicking on the corresponding flag symbol and then enter
the product order number in the search box. The EU Declaration of Conformity is
available for download in PDF format.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. Always dispose of the product according to the relevant statutory
regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.

Technical Data

Battery .......................................... LiPo, 80 mAh
Charging current ........................... max. 60 mA
Charging time ............................... 1.5 – 2 h
Operating time .............................. 4.5 h (at 75 – 80% volume)
Bluetooth version .......................... V4.2
Bluetooth profiles .......................... A2DP, AVRCP
Radio frequency ........................... 2402 – 2480 MHz
Transmitting power ....................... 8 dBm
Range ........................................... max. 10 m
Protection class ............................ IPX4
Operating conditions ..................... -10 to +50 °C, max. 90 % RH
Storage conditions ........................ -10 to +60 °C, max. 90 % RH
Weight .......................................... 17 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
Briefly press the O button
Press and hold the + button for 2 seconds
Press and hold the – button for 2 seconds
