Product Diagram; Control Panel - DEEBOT M81 Pro Benutzerhandbuch

2. Package Contents and Technical Specifications

2.3 Product Diagram

Robot
1
2
3
4
1. Top Cover
2. Dust Bin
3. AUTO Mode Button
4. Anti-Collision Sensors
5. Anti-Drop Sensors

Control Panel

1
2
Charging Dock
1
2
5
6
13 14 15
7
8
6. Charging Contacts 11. Side Brushes
7. Main Brush 12. Advanced Wet/Dry Reservoir Slots
8. Driving Wheels 13. Multi-Function Cleaning Tool
9. Universal Wheel 14. Upgrade Port (for Customer Service only)
10. Battery Pack 15. Infrared Receiver for the Remote Control
1. AUTO Mode Button
2. Wi-Fi Indicator Light
1. Infrared Signal Generators
2. Charging Dock Pins
9
10
11
12
7
