Replacement Parts

1
2
8
5
6
8
4
3
www.masterappliance.com
7
Item Part Number Description
1 35442 Knobs (2)
2 35443 Switch and Loc
3 35444 Cordset Assem
35452 Cordset Assem
35453 Cordset Assem
4 35445 Ribbon Cable
5 35446 Heating Elemen
35451 Heating Elemen
6 35447 Housing Kit
7 35448 Nozzle and Har
8 35449 Sensor Cartridg
