Totally Wicked Tempest Bedienungsanleitung

BATTERY OPERATION:
Power on and off: Press the power button 5 times in
quick succession, the power button light will flash 5
times to indicate Tempest is ready for use. to turn off,
press the power button 5 times in quick succession.
Vaping: Press the power button as you inhale, release
the button when you stop inhaling. When the power
button is held down, the light will be on.
CHARGING:
The battery can be recharged using the supplied USB
cable plugged into a dedicated USB port or wall adaptor.
The power button light will flash white 5 times and
illuminate red until charging is complete.
BATTERY DISPLAY FUNCTION:
The power button light illuminates whilst being pressed,
and on release flashes at increased frequency as the
battery becomes discharged.
Battery charge remaining
60%-100% Stays lit for 6 seconds
30%-59% Slowly flashes for 6 seconds
10%-29% Moderately flashes for 6 seconds
0-9% Flashes repeatedly for 6 seconds
TO FILL THE TANK:
• Invert the complete device and unscrew the
battery from the tank.
• Fill the tank up to but not beyond the
level of the central tube taking care to
avoid liquid entering the central tube.
• Attach the battery to the inverted tank.
ATOMIZER HEAD REPLACEMENT:
• Invert the complete device and unscrew
the battery from the tank.
• Unscrew the atomizer head and remove
from the integrated battery base.
• Screw the new CL atomizer head into
place and firmly tighten.
• Refit the battery to the inverted tank.
PRECAUTIONS
• Tempest sub coil will only work
with batteries that support sub
ohms.
• Please power-off the Tempest when
not in use.
• Do not to press the button if the
Tempest is not in use.
• Store the Tempest e-cigarette and
its accessories away from children
whilst not in use.
• Please only use the charging cable
provided.
• Please dispose of dead batteries
in accordance with your country's
appropriate legislation.
Manufactured in China by Joyetech under
the authority of Pillbox38 UK Ltd, Stancliffe
Street, Blackburn, Lancashire, BB2 2QR.
ADJUSTING ATOMIZER AIRFLOW
Rotate the ring on the atomizer base to cover/reveal
the airflow holes to increase/decrease the airflow to
the atomizer.
SHORT CIRCUIT PROTECTION:
• If a short circuit occurs, before power is applied,
the power button light flashes 5 times and then
powers off.
• If a short circuit occurs during use, the power button
light flashes 3 times.
• In both cases the atomizer head should be changed.
ATOMIZER PROTECTION:
The Tempest has a 15 second time out protection. The
power button light will flash 10 times if the power button
is pressed for more than 15 seconds.
LOW VOLTAGE PROTECTION:
If the battery voltage drops lower than 3.3V, the power
button light flashes for 40 times and the device will
power-off. Charge the device before further use.
RESISTANCE TEST:
• If the resistance of the atomizer is greater than 5.0
ohms, the power button light flashes slowly when
you press the power button and the device will not
function.
• If the resistance of the atomizer is less than 0.3
ohm, the power button light flashes quickly 5 times,
indicating the ohms resistance is too low.
• Do not charge the battery in a
damp environment, in temperatures
under 0°C or above 45°C.
• Do not carry batteries in a pocket
or bag with other metallic objects.
• Do not attempt to repair a faulty
Tempest power unit as these are
sealed units with no serviceable
parts and may lead to further
damage to the item and/or personal
injury. Attempted repairs will void
the warranty.
UK: Tel 01254 692244 www.totallywicked-eliquid.co.uk
USA: Tel 1(888) 761-9425 www.totallywicked-eliquid.com
GER: Tel 01803 942533 www.totallywicked-eliquid.de
USER GUIDE
WARRANTY
The Tempest components
contained in each kit have a
28-day parts warranty with the
exception of the atomizer heads
which are covered by our Dead
On Arrival warranty only. The USB
cable supplied has a 12-month
warranty. If any parts are found to
be faulty within this time please
contact our customer service
team, whose details are on the
back page of this booklet and we
will arrange for a replacement.
We may require the goods to be
returned for further investigation.
