Cherry Power WheelMouse Anleitung Seite 6

You must first switch off the PC if you connect the
receiver to the PS/2 port of the PC by means of the
adapter.
You can connect the receiver to the USB port of
the PC while the PC is running.
Under Windows 95 and Windows NT you can
only use the Cherry Power WheelMouse
wireless optical by means of the USB-PS/2
adapter, since Windows 95 and Windows NT do
not support USB.
To insert the batteries into the Cherry Power
WheelMouse wireless optical
1 Open the battery compartment on the underside
of the mouse.
2 Insert the two included batteries, type AA, into
the housing.
3 Close the cover.
Positioning the receiver on the desk
If your desk has a wooden surface, you can
achieve optimal receipt conditions by positioning
the receiver horizontally.
If your desk has a metal surface, you can achieve
optimal receipt conditions by positioning the
receiver vertically. You can use the base of the
receiver to this purpose.
To connect the receiver to your PC via
the USB port
1 Locate a USB port on the rear of your PC.
2 Remove the USB-PS/2 adapter from the USB
connector of the receiver cable.
3 Connect the receiver connector with the USB
port.
To connect the receiver to your PC via
the PS/2 port
1 Locate the round 6-pin PS/2 mouse port on the
rear of your PC.
2 Connect the PS/2 connector of the USB-PS/2
adapter with the PS/2 port of the PC.
To activate the signal transfer between the
receiver and the mouse
1 Locate the activation button on the receiver.
2 Press the button for a few seconds.
The LED of the receiver is activated and lights up
for approx. one minute.
3 Locate the activation button on the underside of
the mouse.
4 Use a pointed object, e.g. a ballpoint pen, to
press the activation button for a few seconds.
The LED of the receiver extinguishes. The
mouse is ready to operate.
5 Installing the mouse under
Windows 95/98/ME/NT4/2000
To install the software under
Windows 98/ME/2000
1 Place the enclosed CD-ROM in your CD-ROM
drive.
The CD-ROM starts automatically. The Cherry
Power WheelMouse optical window is opened.
-OR-
If the CD-ROM does not start automatically,
select CD-ROM drive | Software in the
Explorer and double-click with the left mouse
button on the file Setup.exe.
Installation begins.
5
