Using the Pairing Button
1. You may use the pairing button after you have changed the batteries (you need to set up
the LMP Keypad like you did for the first time) or when the connection is constantly lost.
Follow steps 1 ~ 8 above.
2. If you have used the LMP Keypad with another Macintosh™ computer, you have to set up
the LMP Keypad again. Follow steps 1 ~ 8 above.

Power Management

To save power, it is highly recommended to power off the LMP Keypad if the
LMP Keypad won't be used for a longer period.
1. To power off the LMP Keypad, hold the power button of LMP Keypad about 3 seconds
until green LED indicator is turned off. You should see the message "lost connection" on
you screen. The LMP Keypad is in power off mode.
2. To power on the LMP Keypad again, hold the power button of the LMP Keypad for 1
second. The LED indicator flashes in yellow. You may see the message "connected" on
your screen. You can use the LMP Keypad now.
The pairing time of LMP Keypad with your Macintosh™ computer normally just
takes a few seconds. However, it may take up to 40 seconds with some
Bluetooth dongles.
3. The LMP Keypad greatly reduces the power consumption automatically when it is in idle
mode (connected, but no keying). In fact, the power consumption in idle mode is only
about ¼ (about 0.65 mA) of the consumption of the keying mode (typing on the LMP
Keypad; about 3 mA). This feature greatly extends the battery life.
4. The LMP Keypad uses 2 pcs. AA size batteries. You can either use non-rechargeable or
rechargeable batteries.
LMP Keypad Manual 1.0
Connecting with Apple™ wireless keyboard (A1314)
1. Connect the linkage bar to the LMP Keypad on its left side by simply sliding it into the
opening. It will nicely form a Keypad unit ready to be linked to the Apple™ wireless
keyboard.
2. Connect the Keypad unit to your Apple™ wireless keyboard (A1314) by sliding the right
side into the LMP Keypad unit as shown in figure shown below. You now have a full size
Bluetooth wireless keyboard ready for use!
3. You can turn on/off the Apple™ wireless keyboard with the power on bar of the LMP
Keypad situated on the right side and upper right corner of the LMP Keypad. To turn on
the Apple™ keyboard, press the power on bar of the LMP Keypad for 1 second. To turn off
the Apple™ wireless keyboard, press the power on bar for about 2 ~ 3 seconds.
Make sure the Apple™ wireless keyboard is firmly plugged into the LMP
Keypad unit.
