2. Components
of the 508C meter
1
2
3
4
5
6
7
8
1 - Flexible sensor
2 - Sensor connector
3 - Power switch
4 - Belt unit weight key
5 - Belt width key
6 - Up button
7 - Down button
8 - Frequency range button
9 - LCD screen with backlight
10 - Measure key
11 - Belt span length key
12 - Frequency/tension display key
13 - Data selection key
14 – Batteries
