Gates Sonic tension meter
UK
manual
Contents Page
F

1. Important warnings .....................................2

2. Components of the 508C meter ..................3
3. Operating procedure for the 508C meter ...4
I
4. Sonic tension meter operating theory ........7
5. Belt installation tension ...............................8
6. Tips on using the Sonic tension meter .......8
E
7. Meter recalibration for non-standard belts ..10
8. Summary of features .................................10
9. Optional accessories ..................................10
NL
10. Warranty and service .................................11
11. Belt unit weight calculation .......................11
D
Thank you for purchasing the Gates Sonic
tension meter. Please read this manual
thoroughly to fully utilise all the meter's
PL
functions.
R
1. Important warnings!
TJ > Do not drop this unit. Impact of any kind
can result in damage.
> Do not disassemble the unit.
> Do not put the unit in a place where fire or
explosion is possible.
> Do not put water, solvent or any other
liquids on this unit.
> Do not leave this unit in a dusty
environment.
> Do not leave this unit where it will get hot,
such as in a car or in direct sunlight.
> Do not use volatile solvents to clean this
unit.
> Do not use this in an area where a spark
could cause an explosion.
> Do not bend the flexible arm sensor
(microphone) within 20 mm (3/4 inch)
of either end. Its construction is tubular,
and it should not be bent at sharp angles.
2
