ENGLISH:
Battery Charging – See Figure 2
Supplied with headlamp: Self-contained
rechargeable battery, micro-USB charging cable.
Princeton Tec suggests using a charger with output of
5V, 1A. This charger will fully charge the battery pack
in 3 to 4 hours. Slower charging will be achieved with
a charger rated for lower amperage. Some computer
USB ports may not have sufficient output to charge
this or any USB rechargeable product. Under normal
usage, the supplied lithium ion battery pack will last for
approximately 1,000 charge / discharge cycles.
Red battery charge level LEDs indicate battery state.
Red LEDs flash when charging is in progress. Charging
has completed when both LEDs are illuminated. Charge
state will be indicated upon lockout, via 1, 2, 3 or 4 LED
flashes, corresponding to approximately 25%, 50%,
75% and 100%.
Princeton Tec cares about the environment and
recommends recycling batteries. For more information
about battery recycling, please
batteryrecycling.com.
!
WARNING
Do not disassemble; no user serviceable parts.
General Care and Warnings
• Properly charge the battery to maximize its lifespan.
Lithium ion batteries do not suffer from a "memory
effect, " and for battery longevity it is preferable to
charge more frequently if possible, rather than to fully
deplete the battery's charge.
• To avoid damaging your lighting system, use only
chargers that meet the approved specifications.
• Axis Rechargeable is not submersible. Submerging
in water will damage the lighting system and void the
warranty.
• To keep your lighting system looking new, use a
mild soap and water solution with a rag or sponge to
periodically wipe off dirt.
Switch Operation – See Figure 1
A single press turns on Red Ultrabright mode at 50%
output. Double tap turns on White Spot Maxbright mode
at 60% output. Press and hold turns on White Flood
Maxbright mode at 25% output. In any mode, the dial is
used for dimming. Beginning in Red mode, any dial turn
will alter the red output. Beginning in White Flood mode
and increasing output, it is possible to continue turning
dial to activate Spot mode in addition to Flood mode;
this will achieve maximum output in what is called Dual
Beam mode. Beginning in Spot mode, dimming action
will be restricted to spot mode only.
A single press occurring more than two seconds after
the previous button press will turn the light off.
Axis is equipped with a battery lockout to prevent
accidental activation. See Figure 1.
Troubleshooting
If the Axis fails to light:
• Check the charge state of battery by either 1. Locking
out the light by holding down the power button, or 2.
Plugging light into power source and observing battery
charge level LEDs.
Figure 1 - Switch Operation
Red & Spot Mode: Turn dial to brighten or dim
Modes Rouge et Spot blanc: Tourner la molette pour augmenter/diminuer l'intensité
Rotlicht u. Spotlicht: Einstellring zum Anheben/Absenken der Helligkeit drehen
lithium
• Princeton Tec calculates total burn time as the time it takes for the light source to produce a minimum of 0.25 lux
at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.
• Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe erzeugte minimale
Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux entsprechen in etwa der Beleuchtungsstärke des
Vollmonds in einer klaren Nacht.
• Princeton Tec définit la durée totale d'éclairage comme le temps nécessaire à la sourc umineuse pour produire
un minimum de 0,25 ux à 2 mètres. 0,25 lux équivaut à peu près à laluminosité d'une pleine lune dans un ciel
go to www.
nocturne dégagé.
Figure 2 – Battery Charging | Voir le schéma 2 – Charge de la batterie | Siehe Abbildung 2 - Laden der Batterie
1
• Check the light for water contamination on the circuit
board. The light will resume normal operation once the
water is shaken or blown out and the light is left until
completely dry. If the light has been contaminated
with salt water, flush the unit with fresh water and dry
as described above.
USA– International 5-Year Warranty
WARRANTY – Princeton Tec warrants this product to
be free from defects in workmanship and materials
under normal use for 5 years. This warranty covers all
of the component parts of the product except batteries.
This warranty does not cover deterioration due to
normal wear or damage due to misuse, alteration,
negligence, accidents, or unauthorized repair. Princeton
Tec will repair or replace parts which are defective in
workmanship or materials.
Your authorized Princeton Tec Dealer and Princeton Tec
are the only facilities authorized to repair the product.
After (3) unsuccessful attempts (within the warranty
period) to repair the product, you have the right to
elect replacement of the product or a refund of the
purchase price less allowance for use of the product.
NO INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARE INCLUDED IN THIS WARRANTY. (Some states
do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you.) This warranty gives
you specific legal rights, and you may also have other
rights which vary from state to state.
Modes de fonctionnement
Press 1x: Red 50%
RED
Appuyer 1x: Rouge à 50 %
1 x drücken: Rotes Licht bei 50%
Press 2x: White Spot 60%
Appuyer 2x: Spot blanc à 60 %
2 x drücken: Weißes Spotlicht bei 60 %
Press & Hold: White Flood 25%
Maintenir appuyé: Projecteur blanc à 25%
Drücken und halten: Weißer Breitstrahler bei 25%
4 MODES / DIMMABLE
2 H
DUAL BEAM HIGH Total burntime
DUAL BEAM LOW 3 H
SPOT HIGH 2 H
SPOT LOW 17 H
FLOOD HIGH
8 H
FLOOD LOW 54 H
RED HIGH 32 H
138 H
RED LOW
DISTANCE
0 2 4 5 12 14
(METERS)
2
Schalterbetätigung
Press 1x from On: Off
Appuyer 1x lampe allumée : Extinction
In eingeschalt. Zust. 1 x drücken: Aus
Press 5 seconds: Lock-Out
Appuyer 5 secondes lampe éteinte: Verrouillage
In ausgeschalt. Zust. 5 Sekunden drücken: Sperre aktivieren
Press 5 seconds from Lock: Unlock
Appuyer 5 secondes lampe verrouillée: Déverrouillage
In gesperrtem Zust. 5 Sekunden drücken: Sperre deaktivieren
Flood Mode: Brightens into dual beam mode
Mode Projecteur: Hausse d'intensité jusqu'au mode Double faisceau
Breitstrahler: Helligkeit steigt bis in den Doppelstrahl-Modus
BEAM DISTANCE
33 m 31 m 0 m
26 m 25 m 0 m
0 m
27 m 25 m
9 m
12 m 10 m
14 m 13 m 0 m
5 m 5 m 5 m
3 m
4 m 4 m
1 m
2 m 2 m
0 H 0.5 H 10 H
26 27 33
T= Time/ Zeit/ Temps Time/ Time/ Temps Temps
3
Princeton Tec reserves the right to change product
specifications without notice.
FOR CALIFORNIA RESIDENTS:
WARNING: This product contains Bisphenol A (BpA) a
chemical known to the State of California to cause birth
defects or other reproductive harm.
Return Policy
If your light fails to operate, follow these simple steps:
1) Check batteries. Replace if necessary.
2) To send your light in for repair or replacement,
first contact Princeton Tec customer service on
1-800-257-9080 to request an RMA number. Please have
your light model, date of purchase and a brief description
of the fault you are experiencing. No warranty repairs
will be accepted without an RMA number.
3) Return the light without
Princeton Tec, PO Box 8057 Trenton NJ 08650. Postage
due and freight collect items will not be accepted.
4) Upon receipt your light will be processed in about
two weeks. Please allow additional time for return
transportation from NJ.
Princeton Tec
PO Box 8057 ,
Trenton, NJ 08650
Phone: 609-298-9331
Fax: 609-298-9601
princetontec.com
