5.1 Discharging the Device before Maintenance
1. Unplug the device from the mains.
2. Use a screwdriver with an insulated handle. Make sure you hold the
screwdriver by the handle only.
3. Short-circuit the 2 wires of the inner metal grid by gently touching them
simultaneously with the metal shaft of the screwdriver. This may cause a
spark.
4. Repeat until no more sparks appear.
5.2 Cleaning the Device
1. Make sure the power switch [A] is in the OFF position and the power plug is
disconnected from the mains outlet before starting any maintenance activity.
2. Discharge the device.
3. Slide the insect collector tray [C] out of the device to dispose of dead insects.
4. Clean the insect killer regularly with a dry, clean cloth. Do not submerge in
any liquid.
5. Make sure that no dust accumulates on the UV lamps, as this will greatly
reduce their effectiveness.
6. Only use a plastic brush to clean the high-voltage grid. Brush gently to avoid
damage.
5.3 Replacing Lamps and Starters
When the lamps are worn, you must replace them with an identical type (see
Technical Specifications).
1. Make sure the power switch [A] is in the OFF position and the power plug is
disconnected from the mains outlet before starting any maintenance activity.
2. Discharge the device.
3. Remove the two screws of the device (indicated by the arrows in the
illustration on page 2).
4. Gently pull the outer grid; it will rotate around the screws at the bottom.
5. To remove a UV lamp, gently turn it a quarter turn and pull it upwards out of
the sockets.
6. Place a new UV lamp into the socket and turn it a quarter turn to secure it.
7. To replace a starter, turn it a quarter turn and pull it out of the socket.
8. Insert a new starter with the same specifications into the socket and turn it a
quarter turn to secure it.
9. Close the outer grid and fix the two screws.
