System Data
Signal-to-noise ratio
Frequency Response
Mic input
Line input
Function Controls
GAIN
OUTPUT
Preamp mode control
Function Switches
20 dB PAD
+48 V
LOW CUT
PHASE REVERSE
Indicators
Input Level
Power LED
90 dB A-weighted @ -28 dBu input level
<10 Hz to 47 kHz (±3 dB)
<10 Hz to 55 kHz (±3 dB)
variable (+26 dB to +60 dB)
variable (-∞ to +10 dB)
selection of various preamp settings for microphone
and instruments
level attenuation (20 dB)
activates the phantom power
High pass filter (cut-off frequency 90 Hz)
Phase reverse (180°)
8-segment LED meter:
-24, -18, -12, -6, 0, +6, +12, Clip
indicates operation
