Specifications - Furman Classic PL-8C E Handbuch

SPECIFICATIONS

CURRENT RATING:
10 amps
OPERATING VOLTAGE:
180 to 274 VAC
OVER VOLTAGE SHUTDOWN:
275 VAC typically
SPIKE PROTECTION MODES:
Line to neutral, zero ground leakage
SPIKE CLAMPING VOLTAGE:
376 VAC peak @ 3,000 Amps, 266 VAC RMS
RESPONSE TIME:
1 nanosecond
MAXIMUM SURGE CURRENT:
6,500 amps
NOISE ATTENUATION:
10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz
Linear attenuation curve from 0.05 - 100 Ohms line impedance
DIMENSIONS:
44.45mm H x 482.6mm W x 266.7mm D.
WEIGHT:
4.5 kg
CONSTRUCTION:
Steel chassis, 3mm brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
POWER CONSUMPTION:
25 VA
SAFETY AGENCY LISTING:
CE
8
PL-8C E OWNER'S MANUAL
