Handheld transmitter
model H02
WARNING: the transmitter needs to be programmed in the receiver's memory. To do this, follow the procedure shown in
the receiver's user manual.
Power supply
The handheld transmitter is powered using 3 AAA alkaline or rechargeable batteries.
To replace them, see the BATTERY REPLACEMENT paragraph.
Enabling
The handheld transmitter is enabled by keeping the ON/OFF button pressed. When pressed, it starts to flash regularly and then
starts flashing more quickly. After it is released, it remains on for 3 seconds and then, by means of a short flashing, it shows
that enabling has taken place.
If the ON/OFF button is released before it flashes quickly, the transmitter is not enabled and is off again.
Operational status
While pressing any key the blue transmission LED flashes quickly and signals that transmission has taken place. It is possible to
press up to two keys at the same time, while pressing 3 or more keys simultaneously cancels transmission (transmission LED
switched off).
Each key pressed corresponds to the activation of a relay on the receiver (see RRC radio receiver manual), which will stay
active as long as the key isn't released.
RRC H02/12 - REV001B
Transmission LED
model H04
Backlit ON/OFF button
OPERATION
model H12
