Mini soundmodul mit 128 gm sounds
dreistelliges display
volume-, program und reverb taster
data input drehregler
usb host anschluss für usb keyboards
integrierter akku mit 2500mah
micro usb anschluss zum aufladen
midi input über adapter
kopfhörer/
Gitarre/bass und instrument zu iphone/ipad adapter (4 Seiten)
Inhaltszusammenfassung für Miditech Pianobox mini
Seite 1
Pianobox mini MINI Soundmodul mit 128 GM Sounds Dreistelliges Display Volume-, Program und Reverb Taster DATA Input Drehregler USB Host Anschluss für USB Keyboards Integrierter Akku mit 2500mAh Micro USB Anschluss zum Aufladen MIDI Input über Adapter Kopfhörer/LINE-Ausgang 3,5mm...
Bedienungsanleitung Vielen Dank, das Sie sich für die Miditech Pianobox MIni entschieden haben. Die Pianobox Mini stellt Ihnen zum günstigen Preis ein GM Soundmodul zur Verfügung. Angeschlossen an ein Masterkeyboard können Sie mit der Pianobox Mini direkt spielen! Die 3 Funktionstaster und das DATA Input Drehrad ermöglichen eine leichte Sound- und Lautstärke- Auswahl.
Seite 3
5. Reverb Knopf 6. DATA Entry Drehrad Bedienung der Pianobox mini Die 3 Funktionstaster der Pianobox mini sind mit ihrer Funktion beschriftet. Hier die Funktionen: 1) Volume: Drücken Sie „Volume“, der Taster leuchtet rot. Jetzt können Sie mit dem DATA Input Drehregler die Lautstärke einstellen, die im Display zur Kontrolle angezeigt wird.
Seite 4
Pianobox mini. Danach können Sie Ihr Keyboard oder MIDI Interface über ein handelsübliches DIN MIDI Kabel verbinden. 3) Der USB HOST Port der Pianobox mini dient zum direkten Anschluss per USB Kabel von handelsüblichen USB Masterkeyboards. Diese werden über den USB Host Port mit Strom versorgt.
Seite 5
Helicopter Violin Lead 4(Chiff) Applause Viola Lead 5(Charang) Gunshot Cello Lead 6(Voice) Specifikationen PRODUCT SPECIFICATIONS Pianobox mini MODEL NAME MODULE Built-in Sound MAXIMUM POLYPHONY 64 notes INSTRUMENTS 128GM List Sound JACK Headphone (LINE) OUT、MIDI IN、USB host、Micro- Power source Micro-USB (≥500mA)
Seite 6
LED display Volume, program and reverb button Big data input wheel Integrated chargeable battery with 2500mAh USB HOST port Micro USB port to charge the Pianobox mini MIDI Input adaptor LINE OUT/headphone output TRS jack 3,5 mm eMail: info@miditech.de Internet:...
Seite 7
Thanks for purchasing the Pianobox mini. Its compact design won’t cost any space in your working desk or bag, you can bring it easily simply put in your pocket. The Pianobox mini provides 128 GM sounds and built in modulate reverb、chorus for you to make sound richer while you composing or playing.
Seite 8
The power will automatically shut down when less than 5%. ● The Pianobox mini device's USB port (USB HOST) provides a standard USB 5V 500mA current output, your mobile phone can act as emergency mobile charger. ● Power supply: Everywhere Micro-USB charging / power supply (mostly the USB interface on the phone, such as Samsung), pick up your phone charger can charge for our audio / power supply;...
Seite 9
MIDI devices. (Tone sounds and effects can be adjusted via MIDI device itself features). NOTE: When connecting two MIDI devices, data on the Pianobox mini data display is your last operation. When adjusting the tone and effect, make sure the current Pianobox mini control which MIDI devices.
Helicopter Violin Lead 4(Chiff) Applause Viola Lead 5(Charang) Gunshot Cello Lead 6(Voice) Specifications PRODUCT SPECIFICATIONS Pianobox mini MODEL NAME MODULE Built-in Sound MAXIMUM POLYPHONY 64 notes INSTRUMENTS 128GM List Sound JACK Headphone (LINE) OUT、MIDI IN、USB host、Micro- Power source Micro-USB (≥500mA)
