Operating; Slide Switch - Goobay IP20 Betriebsanleitung

95173
Note:
8. Plug the luster terminal onto the provided lugs.
9. Connect motion sensor and cover cap and lock the
connection.
10. Switch on the mains fuse.

Operating

Depending on the design of your motion sensor, it may only have
some of the following options:
SLIDE SWITCH: Select between
ON:
adjustment (PIR).
OFF: All functions are off.
PIR:
PIR+MIC:
96006
L phase (hot)
N zero conductor (ground)
A consumer (lamp)
T he motion sensor works without distance
D istance adjustment is activated.
D istance adjustment and microphone are
activated in addition.
25
