95173: by pushing upwards.
96006: no cover cap included
Choose the installation place away from street lighting, plants or
air conditioning vents. Avoid direct sun insulation eg. neer
windows.
6. Attach the cover cap to a wall or ceiling in a height, menti-
oned in the specifications - with the installation material. At
this, a ttend to the cable location and its alignment. Also
attend to t he detection a rea and max. distance.
7. Install the motion sensor like shown:
Installing
95171
SPLAY BOLT
SPREIZBOLZEN
OPEN FACEPLAT
KAPPE ENTFERNEN
95172
FIXED ARM
FIXIERARM
MOUNTING HOLE
BEFESTIGUNGSLOCH
96005
SPREIZBOLZEN
BEFESTIGUNGS-
LOCH
KAPPE ÖFFNEN
96007
FIXIERARM
