CONTROLS
18
17
1
16
15
14
2
13
3
12
11
10
4
5
6 7 8 9

REAR PANEL

21
19 20 22
DESIGNATION
1. Turntable
2. Hub
3. Voltage Selector
4. ON/OFF Switch Turntable Illumination
5. START/STOP Button
6. 33/45/78 Selector
7. Switch for Stylus Illumination
8. Reverse Switch
9. Pitch Selector
10. Quartz Lock Switch
11. Pitch Fader
12. Headshell with Pick-Up System
13. Pick-Up Arm
14. Pick-Up Rest
15. Pick-Up Lift
16. Anti-Skating Wheel
17. Balancing Weight Scale
18. Balancing Weight
19. Audio Output Cable (RCA)
20. GND Grounding Cable
21. Connection for Remote Control
22. Mains Connection
