• COLOUR MIXING - channel 1 - 2 - 3
Operation with option CMY Off
CHANNEL 1
CHANNEL 2
CHANNEL 3
CYAN
MAGENTA
YELLOW
IMPORTANT: The lamp dim to half power 3 seconds after the channels stay at 0% level.
The lamp goes back to full power when the channels level is put higher than 0%.
Operation with option CMY On
CHANNEL 1
CHANNEL 2
CHANNEL 3
CYAN
MAGENTA
YELLOW
IMPORTANT: The lamp dim to half power 3 seconds after the channels stay at 100%
level. The lamp goes back to full power when the channels level is put lower than 100%.
• C.T.O. - channel 4
• STOPPER / STROBE - channel 5
IMPORTANT: The lamp dim to half power 3 seconds after the channel stay at
0% level. The lamp goes back to full power when the channel level is put
higher than 0%.
ALPHA WASH EASY 12
BIT
%
EFFECT
255
100
COLOUR EXCLUDED
0
0.0
COLOUR INSERTED
BIT
%
EFFECT
255
100
COLOUR INSERTED
0
0.0
COLOUR EXCLUDED
BIT
%
EFFECT
255
100
FILTER INSERTED
0
0.0
FILTER EXCLUDED
BIT
%
EFFECT
252 - 255
98.7 - 100
OPEN
239 - 251
93.7 - 98.2 RANDOM FAST STROBE
226 - 238
88.7 - 93.2 RANDOM MEDIUM STROBE
213 - 225
83.7 - 88.2 RANDOM SLOW STROBE
208 - 212
81.7 - 83.2 OPEN
207
81.2
FAST PULSATION
108
42.5
SLOW PULSATION
104 - 107
41.0 - 42.0 OPEN
103
40.5
FAST STROBE (12 flash/sec)
4
1.7
SLOW STROBE (1 flash/sec)
CLOSED
0 - 3
0.0 - 1.2
• DIMMER - channel 6
IMPORTANT: The lamp dim to half power 3 seconds after the channel stay at
0% level. The lamp goes back to full power when the channel level is put
higher than 0%.
• FROST - channel: 7
• OVALIZER - channel: 8
27
BIT
%
EFFECT
255
100
DIMMER OPEN
0
0.0
DIMMER CLOSED
BIT
%
EFFECT
170 - 255
66.7 - 100
HEAVY FROST
85 - 169
33.2 - 66.2 LIGHT FROST
WHITE
0 - 84
0.0 - 33.0
BIT
%
EFFECT
255
100.0
FAST ROTATION
193
75.5
SLOW ROTATION
191-192
74.7-75.0
STOP
190
74.2
SLOW ROTATION
128
50.0
FAST ROTATION
127
49.7
OVAL INSERTED
0
0.0
OVAL EXCLUDED
