1.
Contenuto della confezione
1x IB-241WP, 1x USB 3.0 cavo di dati, viti, 1x manuale
2.
Caratteristiche
•
Interfaccia USB 3.0 Host 5 Gbit/s
•
Supporto SATA III 6 Gbit/s e UASP
•
Custodia in alluminio compatto
•
Display a LED per l'alimentazione e l'accesso di HDD
•
HDD 7 - 9,5 millimetri di altezza, capacità non limitato
•
Supporta: PC, Mac, Linux
•
Hot Plug & Play e Hot Swap
•
Interruttore per la protezione da scrittura
•
Contro la perdita di dati / infezione da virus
3.
HDD/SSD installazione
Staccare tutti i cavi di connessione con il computer durante il montaggio e
lo smontaggio del disco fisso.
1
4
Read-Only-Modalità
1.
Scollegare la IB-241WP dal computer
2.
Premere l'interruttore a sinistra
4.
Applicazione
4.1
Il contenitore esterno può essere collegato direttamente al computer
tramite il cavo USB. Il disco fisso può essere collegato o staccato dal
computer durante il funzionamento di quest'ultimo.
4.2
Attendere la fine di funzioni di lettura e di scrittura prima di staccare un
contenitore esterno collegato al computer, per evitare perdite di dati.
4.3
Ogni nuovo disco fisso deve venir inizializzato, partizionato e format-
tato dal drive, prima di poter essere indicato dal sistema.
4.4
Se il disco fisso non viene riconosciuto subito dal sistema, verificare:
© Copyright 2016 by RaidSonic Technology GmbH. All Rights Reserved
- se il software di drive relativo è installato (USB),
The information contained in this manual is believed to be accurate and reliable. RaidSonic
Technology GmbH assumes no responsibility for any errors contained in this manual. RaidSonic
- se il disco fisso è stato inizializzato, partizionato e formattato.
Technology GmbH reserves the right to make changes in the specifications and/or design of the
above mentioned product without prior notice. The diagrams contained in this manual may also
not fully represent the product that you are using and are there for illustration purposes only.
RaidSonic Technology GmbH assumes no responsibility for any differences between the product
mentioned in this manual and the product you may have.
Manuale: IB-241WP
Manuel: IB-241WP
2.
Contenui de la livraison
1x IB-241WP, 1x USB 3.0 câble de données, vis, 1x Manuel
3.
Caractéristiques
•
Interface USB 3.0 Host 5 Gbit/s
•
Soutien SATA III 6 Gbit/s et UASP
•
Boîtier en aluminium compact
•
Ecran LED pour l'alimentation et l'accès disque dur
•
HDD 7 - 9,5 mm de hauteur, la capacité ne se limite pas
•
Prise en charge: PC, Mac, Linux
•
Hot Plug & Play et Hot Swap
•
Commutateur de protection d'écriture - Contre la perte de données
et une infection virale
4.
Installation HDD/SSD
Devant l'installation ou la désinstallation d'un disque dur il faut débrancher
tous câbles de connexion à l'ordinateur.
2
3
1
2
5
6
4
5
Read-Only-Mode
1.
Débranchez l'IB-241WP de l'ordinateur
2.
Pousser l'interrupteur vers la gauche
5.
Application
4.1
Le boîtier externe peut être connecté directement à l'ordinateur en
utilisant le câble USB. Le disque dur peut être branché ou débranché
de l'ordinateur pendant l'exploitation normale de l'ordinateur.
4.2
Attendez le complètement des écritures et des lectures avant de
déconnecter un boîtier branché à l'ordinateur pour éviter une perte
de données.
4.3
Avant tout, un disque dur nouvel doit être initialisé, partitionné,
et formaté par le système d'exploitation pour être indiqué par le
système.
4.4
Si le disque dur n'est pas reconnu immédiatement par le système,
vérifiez le suivant:
- si le logiciel de pilotes est installé (USB),
- si le disque dur est initialisé, partitionné, et formaté.
Handbuch: IB-241WP
1.
Verpackungsinhalt
1x IB-241WP, 1x USB 3.0 Datenkabel, Schrauben, 1x Bedienungsanleitung
2.
Merkmale
•
USB 3.0 Hostanschluss 5 Gbit/s
•
Unterstützt SATA III 6 Gbit/s und UASP
•
Kompaktes Aluminium Gehäuse
•
LED Display für Betrieb und Festplattenaktivität
•
Festplattenhöhe 7 - 9,5 mm, Kapazität ohne Limit
•
Unterstützt: PC, Mac, Linux
•
Hot Plug & Play und Hot Swap
•
Schalter für Schreibschutz - gegen Datenverlust / Virusinfektion
3.
Festplattenmontage
Beim Ein- und Ausbau der Festplatte müssen alle Kabelverbindungen zum
Computer gelöst werden.
1
2
3
3
4
5
6
6
Read-Only-Modus
1.
Trennen Sie das USB-Kabel von IB-241WP vom Computer
2.
Schieben Sie den Schalter in die linke Position
4.
Anwendung
4.1
Die externe Festplatte kann im laufenden Betrieb des Rechners
an diesen via USB Kabel angeschlossen oder von diesem getrennt
werden.
4.2
Bitte das Ende von Schreib- und Lesevorgängen abwarten bevor ein
angeschlossenes Gehäuse vom Rechner getrennt wird, um Daten-
verlust zu vermeiden.
4.3
Eine neue Festplatte muss vom Betriebssystem erst initialisiert, parti-
tioniert und formatiert werden, um vom System angezeigt zu werden.
4.4
Wenn die Festplatte nicht sofort vom System erkannt wird bitte prüfen:
- ob die Treibersoftware installiert ist (USB),
- ob die Festplatte initialisiert, partitioniert und formatiert ist.
Manual: IB-241WP
1.
Package contents
1x IB-241WP, 1x USB 3.0 data cable, screws, 1x Manual
2.
Key Features
USB 3.0 External enclosure for 2.5" SATA HDD/SSD
•
USB 3.0 Host Interface 5 Gbit/s
•
Support SATA III 6 Gbit/s and UASP
•
Compact aluminum enclosure
•
LED Display for power and HDD access
•
HDD 7 - 9,5 mm height, capacity not limited
Externes USB 3.0 Gehäuse für 2,5" SATA Festplatte/SSD
•
Supports: PC, Mac, Linux
•
Hot Plug & Play and Hot Swap
•
Switch for write protection - against data loss / virus infection
USB 3.0 Boîtier externe pour 2,5" SATA disque dur/SSD
3.
HDD/SSD Installation
During the HDD/SSD assembly all cabling has to be disconnected from the
computer.
USB 3.0 Caja externa para discos duros/SSD 2,5" SATA
1
2
3
USB 3.0 Obudówa zewnętrzna na dyski/SSD SATA 2,5"
USB 3.0 Externí box pro 2,5" SATA pevné disky/SSD
4
5
6
USB 3.0 Εξωτερική Θήκη για Οδηγούς Σκληρού Δίσκου SATA 2,5"
USB 3.0 externe behuizing voor 2,5" SATA HDD/SSD
Read-Only-Mode
1.
disconnect the IB-241WP from the Computer
2.
push the switch to the left
4.
Application
4.1
The external HDD/SSD can be connected to or disconnected from
the computer via USB cable without shutting down the computer.
4.2
Please await the end of read/write operations before disconnecting
the HDD to avoid data lost.
4.3
A new HDD/SSD must first be initialised, partitioned and formatted
by the operation system to be displayed by the system.
4.4
If the hard disc isn't recognised instantly by the operating system
please check:
- if the driver software is installed (USB),
- if the HDD/SSD is initialised, partitioned and formatted.
Manual: IB-241WP
Handbuch IB-241WP
Manuel IB-241WP
Manuale IB-241WP
USB 3.0 Cassetto per 2,5" SATA HDD/SSD
Manual IB-241WP
Podręcznik obsługi IB-241WP
Návod k použití IB-241WP
Εγχειρίδιο IB-241WP
Gebruikershandleiding IB-241WP
Használati utasítás IB-241WP
USB 3.0 Külső ház mert 2,5" SATA HDD/SSD
