Example 5
Typical High Power Active Filtered BI-AMP Stereo System Setup with Mono Sub (Bridge
Mode)
Only for Q-series
Cutoff Frequency
Sel23/Sel24
65Hz
100Hz
130Hz
Power
Stage
Left or
Right
Channel
Total Zmin = 4 Ohm
SEL1 SEL2
SEL7 SEL8
This case sets the cutoff frequency at 100Hz for both filters.
POWERSOFT
Sel19/Sel20
65Hz
100Hz
130Hz
Power
Stage
To second
Sub woofer
Set control
knobs for
ch3-ch4 on
Front Panel
at same level
Front Panel Selection View
SEL3 SEL4 SEL5
SEL9 SEL10 SEL11 SEL12
APPENDIX - 9
Cutoff Frequency
Sel5/Sel6
65Hz
100Hz
130Hz
Power
Stage
Rear
Panel
View
Only for Q-series
SEL6 SEL13 SEL14
SEL19 SEL20 SEL21
Sel1/Sel2
65Hz
100Hz
130Hz
Power
Stage
1+/1-
1+/1-
Total Zmin = 2 Ohm
SEL15 SEL16 SEL17 SEL18
SEL22 SEL23
A
p
p
Left or
right
Channel
SEL24
