Location Of Controls; Power Supply - Seg BB 1322Princess Bedienungsanleitung

8 10
11 4
16 1 12 14 20 5
1. NEXT button
2. FOLDER UP button
3. CLOCK/ADJ, PROGRAM
(programmed play) button
4. CD compartment
5. ON/STANDBY
6. FUNCTION switch
7. TUNING dial
8. USB port
9. Open/Close CD
10. Handle
Using the AC power supply
Insert the AC power cord into an AC mains outlet with a 230V AC ~ 50Hz power
source and insert the other end into the AC ~ socket at the back of the unit.
Using batteries
1. Open the battery compartment.
2. Insert 6 UM2/ "C" size batteries (not supplied) with the polarities (+/-) matching
the markings in the battery compartment. Reversed batteries may damage
the unit.
3. Close the battery compartment.
Note: When AC power is supplied, the battery power is cut off automatically.
Precautions when using batteries
1. Use only the size and type of batteries specified.
2. Do not mix different types of batteries together (e.g. alkaline, rechargeable and
standard (carbon zinc)) or old batteries with fresh ones.
3. Exhausted batteries must be removed to prevent any battery leakage.
4. Dispose of batteries properly according to environmental regulations.

LOCATION OF CONTROLS

9 7 15 6
3 13 2 16
button

POWER SUPPLY

GB-4
19
11. VOLUME dial
12. PREVIOUS button
13. PLAY/ PAUSE
14. STOP / CD/USB button
15. LCD display
16. Speaker
17. AC ~ socket
18. Battery compartment
19. FM antenna
20. FM stereo LED
18
17
button
