16260 Barbell Rack
Page 10
Cybex Free Weight Owner's Manual
16260 MAIN ASSEMBLY/DECAL DETAIL
8
12X
SEE SERIAL NO
DECAL PLACEMENT
DETAIL
2
X4
1
SEE DECAL
PLACEMENT DETAIL
2X 2.50±.12
2X CENTER DECAL
ON TUBE.
CYBEX DECAL DETAIL
SCALE 1:4
CENTER DECAL
ON TUBE.
1.00±.12
DECAL DETAIL
SCALE 1:4
ITEM QTY PART NO.
1 1 11040-790
2 4 16010-311
3 1 16260-200
4 4 16260-300
5 2 3900-433
6 1 51198
8 12 HN704901
9 12 JC700420
5
SEE CYBEX
DECAL DETAIL
3
5
A
A
DESCRIPTION
DECAL, MADE IN U.S.A.
FOOT PAD
W/ MAIN FRAME BARBELL RACK
BAR PLATE
DECAL, CYBEX 1.00 HOR
WARRANTY BOOKLET (NOT SHOWN)
LOCKNUT, .375-16 NYLON
BHSCS .375-16 X 1.25
4
4X
9
12X
CENTER DECAL
ON TUBE.
1.00±.12
SECTION A-A
SERIAL NO.
DECAL DETAIL
