Auto Mode; Sound Control Mode; Master/Slave Mode - EuroLite LED PMC-25x10W COB RGB 25 Bedienungsanleitung

1. Static colors
2. Dream
3. Meteor
4. Fade
5. Change
6. Flow 1
7. Flow 2
8. Flow 3
9. Flow 4
10. Flow 5
11. Flow 6
12. Flow 7
13. Flow 8
C1: BLA-RGB C2: BLA-RGB
14. Flow 9
C1: BLA-RGB C2: BLA-RGB

Auto Mode

In Auto Mode, the chasers are called up automatically in a continuous loop.
Press the MODE button to select the AUTO mode.
Press the ENTER button to select the desired frequency of the loops.
The desired frequency of the loops (Frequency = FQN 01-99) can be selected via the UP or DOWN buttons.
Please press the ENTER button to confirm and to exit the AUTO Mode.

Sound Control Mode

Press the MODE button and choose Sound Controlled Mode (SOUND).
Press the ENTER button to select the desired sensitivity and frequency of the loops, respectively.
The desired microphone sensitivity (SENS 00-31) and frequency of the loops (FQN 01-99) can be selected
via the UP or DOWN buttons.
Please press the ENTER button again to confirm and to exit the SOUND Mode.

Master/Slave Mode

Press the MODE button to select the SLAVE mode. The devices set in this manner can now be controlled by
the master unit.
Please press the ENTER button to confirm and to exit the SLAVE Mode.
RDM
With this function you can call up various submenus via RDM.
This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of
devices connected to the DMX-bus possible. ANSI E1.20-2006 by ESTA specifies the RDM standard as an
extension of the DMX512 protocol.
Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when
the device is installed in a remote area.
RDM is integrated n the DMX-protocol without influencing the connections. The RDM-data is transmitted via
the standard XLR-poles 1 and 2 – new DMX-cables are not necessary. RDM ready and conventional DMX
devices can be operated in one DMX line. The RDM protocol sends own packages in the DMX512 data feed
and does not influence conventional devices.
If DMX splitters are used and RDM control is to be used, these splitters must support RDM.
The number and type of RDM parameters depend on the (optional) RDM controller being used.
In order to see or to change the RDM PID code if required, press the MODE button and choose FIXTURE
ID.
Press the ENTER button.
Enter the password 050 via the UP or DOWN button.
Blackout, red-green-blue-yellow-cyan-purple-white;
CL: RGB Flash 00 - 99
Seven color dreaming
Seven color flow
Seven color fade
Seven color change
Seven color chase in 1 direction
Seven color chase in 2 directions
Seven color chase relay in 1 direction
Seven color chase relay in 2 directions
Seven color chase from 2 sides to the middle
Seven color chase from the middle to 2 sides
Seven color chase
Seven color chase in 1 direction
Seven color chase in 2 directions
26/33 00080497, Version 1.0
