INFORMATION E3 E-BIKE V6 / V6s / V1260 / MINI
FOR ALL FRONT LIGHTS
> Never use a high-pressure hose to clean the light. The lens is held in place with a
spring. The pressure of a water jet would push it back - water will get into the
sealed housing and can not get out again.
> Always connect the front and rear light with the 2-core wire (no mass connection
to the frame!)
> The cable exits have to point downwards to keep the housings waterproof.
E3 E-BIKE V6/V6s
The V6/V6s has been designed for use on regulated 6 volt E-bike systems. The light
is not designed to be connected to a 6 volt battery, because it would have a higher
voltage when fully charged.
PLEASE NOTE:
The 6 volt light port of the Bosch E-Bike system of the first
generation is not strong enough to power this light and can be damaged.
2nd Generation Bosch systems have been adapted to work with Supernova lights.
The light is switched on and off with the main E-Bike control unit.
IMPORTANT: E-BIKE V1260
> When connecting the light please connect correct polarity:
Red cable=positive (+) black cable=negative (-)
> An incorrect connection will damage the light.
> The light can be used on 12-60 volt direct current (DC)
> The rear light cables are red (+) and blue (-) and are supplied 6 volt DC and
100 mA current. Higher currents will damage the light.
> Only use Supernova rear lights! All other rear light can damage the electronics.
> Always insulate loose cable ends on the front light, if no rear light is installed.
E3 E-BIKE MINI
> The light can be powered with 4-10 Volt direct current (DC).
> Please always use the washers supplied when installing the light.
