Using the OSCAR interface
Key, key combination,
or mouse action
F1
Escape
Alt+X
Alt+O
Alt+ port number
Enter
Print Screen, Backspace
Print Screen, Alt+0
Print Screen, Pause
Up Arrow or Down Arrow
Right Arrow or Left Arrow
Page Up or Page Down
Home or End
Delete
Table 2: OSCAR interface navigation basics (Continued)
16
Result
Display help for the current window.
In the OSCAR main window: Close the OSCAR
interface and return to the status flag on the desktop.
In all other windows: Close the current window, without
saving changes, and return to the previous window.
In pop-up windows: Close the pop-up window and return
to the current window.
Close the current window, without saving changes, and
return to the previous window.
Click OK and return to the previous window.
Select a target device to be scanned; port number is the
port number of the target device.
Completes a switch in the Main window and exits the
OSCAR interface.
Click on an editable field to select the text for editing and
enable the Left and Right Arrow keys to move the
cursor. Press Enter to quit the edit mode.
Return to the previously selected target device.
Disconnect the user from the selected target device.
Note that the zero must be typed on the main keyboard,
not the numeric keypad.
Start the screen saver immediately and lock the user, if
it is password-protected.
Move the cursor from line to line in a list.
When editing text in a field: Move within the text in the
field.
All other conditions: Move the cursor from column to
column in a list.
Page through a list or help window.
Move the cursor to the top or bottom of a list.
Delete the selected characters in a field or the selected
item in the scan list. For more information about scan
lists see "Scanning the switching system" on page 30.
Basic operations
