Horizontal set up
2.3
If you choose to use your speakers in horizontal position as indicated below,
please make sure that the set up is mirror symmetrical, i.e. that the
tweeters both face either the outsides or the insides. This is crucial for a
precise stereo signal.
2.4

The Stereo Triangle

If the loudspeaker is going to be used for stereo applications, the optimum
listening position should be located in the middle of a stereo triangle. This
means that your listening position will be located at the top of an imaginary
equilateral triangle and the two loudspeakers should be placed at the other
two points of this triangle.
6
2.
Speaker Placement
Figure 3: horizontal / mirror symmetrical set up
so:
oder so:
Figure 4: Stereo Triangle
• both loudspeaker and the listening
spot should be a equilateral triangle
• approx. the same distances
between loudspeakers and the lou-
dspeakers / the listening spot
• alignment towards listening spot
