11.
ADAM P22A - active 2-ways bass reflex loudspeaker
Woofer
Basket ø
ART Tweeter
Diaphragm area
Equivalent diaphragm ø
Speed transformation ratio
Diaphragm weight
Built-in amplifiers
AC Voltage
Woofer channel (*1 / *2)
Tweeter channel (*1 / *2)
Control Panel
Input Sensitivity
Low shelve > 6 kHz
High shelve < 150 Hz
Tweeter gain
General Data
Frequency response
Crossover frequency
THD >80 Hz at 90 dB in 1 m
Short time sine wave acoustic output at 1
m, 100 Hz - 3 kHz
Max. peak acoustic output in 1 m per pair
Impedance
Height x Width x Depth
Weight
Warranty
Input
Operating temperature
Storage temperature
Humidity
*1 = long term IEC 265-8-Wrms / 10 min
*2 = nominal IEC 265-8 = Peak Power 5 µsec
*3 = pay attention to the selected voltage on the rearside of the speaker

Technical Data

1
8.5" / 215 mm Nomex®
1
2830 mm
60 mm / 2.5"
4:1
0,17 g
2 (Class 1)
100-120V~, 50/60Hz *3
220-240V~, 50/60Hz *3
100 W / 150 W
100 W / 150 W
±10 dB
± 6 dB
± 6 dB
± 4 dB
38 Hz - 35 kHz
1800 Hz
≤ 1%
≥110 dB
≥120 dB
10 kΩ
430 x 260 x 340 mm
13 kg (28.7 lb.)
5 years
XLR
0° C bis 40° C (32° F bis 104° F)
-30° C bis 70° C (-22° F bis 167° F)
Max. 90% not condensing
2 / 4.5 inch 2
15
