7.3

Removing the measuring transducer (optional)

• Disconnect the connecting cable of the measuring transducer in the control cabinet.
• Then disconnect the cable feed-through from the bottom of the control cabinet and pull
the cable back carefully.
• Remove any UV-stabilized cable binders used to secure the connecting cable to the
pole.
7.4

Removing the solar cable

• Disconnect the solar cable at the connection terminal blocks (see Figure 8-1 on
page 165) of the charge controller in the control cabinet.
• Disconnect the (M16) cable feed-through from the bottom of the control cabinet and
pull the solar cable back carefully.
• Remove any UV-stabilized cable binders used to secure the solar cable to the pole.
7.5

Removing the solar panel

NOTE: Damage to the solar system during uninstallation
Due to the high value and weight of the solar panel and control cabinet, the solar system
should always be uninstalled by two people.
WARNING: Danger of cutting and crushing
Please note there is a danger of hands being cut or crushed when uninstalling the solar
panel. Therefore, this work should always be carried out by two people.
• To prevent injury, wear protective gloves.
• Detach both pole brackets of the solar panel using a suitable tool.
• Place the solar panel on a clean, scratch-free surface.
• If necessary, clean any heavy dirt from the solar panel.
