Quick Setup Guide

Front Panel Connector

HD-LED
(Primary/Secondary IDE LED)
G-LED
(Green LED)
Reserved
G-SW
(Green switch)
RESET
(Reset switch)
SPEAKER
(Speaker connector)
PWR-LED
(Power/Standby LED)
16
1 2
HD-LED
RESET
J21
SPEAKER
1 9
Pin
Pin Assignment
3
HDD LED Power
5
HDD
1 4
Green LED Power
1 6
Ground
8
N. C.
1 0
N. C.
1 8
Ground
2 0
SMI
7
Ground
9
H/W Reset
1 3
Speaker Data
1 5
N. C.
1 7
Ground
1 9
Speaker Power
2
LED Power (+)
4
LED Power (+)
6
LED Power (-) or Standby Signal
PWR-LED
G-LED
G-SW
2 0
