Quick Setup Guide
IDE Disk Drive Connectors
IrDA Connector
Note:
The sequence of the pin functions on some IR cable may be
reversed from the pin function defined on the system board. Make
sure to connect the cable connector to the IR connector according to
their pin functions.
12
IRRX
N. C. Ground
VCC
IRTX
1 5
3 9
4 0 4 0
2 1 2
Primar y Secondar y
IDE IDE
3 9
1
