INSTALLATION
1. Do not place the detector where its operation will
be easily interfered. Avoid installations in places
with pets, air conditioners and heat sources
nearby, places with direct sunshine and places
under rotating objects.
2. The device should be mounted on a solid and
stable surface.
3. Choose a suitable position. Pull the prepared
power wires and signal wires through the hole in
the detector bracket base and use screws to fix it
onto the wall (fig.1).
4. Lock the flat surface of the bracket ball into the
detector bottom cover (fig. 2).
5. Remove the detector top cover and pull the
power wires and the signal wires through the
round hole in the middle of the bracket ball (fig.3).
6. Connect the wires as in fig. 5. Then insert the
bracket ball with the detector into the bracket
base (fig. 4).
7. Fix the detector top cover and adjust the
installation angle accordingly to demands.
EN
1. Fix bracket base
2. Lock bracket ball
3. Pull through the wires
4. Insert bracket ball & detector
