Wing Assembly - REVELL SA-16B Albatross Handbuch

1
FUSelaGe / nOSe wHeel
SMALL
WINDOW STRIP
CLEAR
ROUND WINDOW
CLEAR
NOSE WHEELS
SEMI GLOSS BLACK
WITH ALUMINUM HUBS
2
13
RIGHT
WING BOTTOM
Kit 0020 - Page 2
ROUND WINDOW
CLEAR
LARGE
WINDOW STRIP
CLEAR
SMALL
WINDOW STRIP
CLEAR
RIGHT
FUSELAGE
NOSE GEAR
STRUT
ALUMINUM

wInG aSSemBlY

11
RIGHT
WING TOP
LARGE
WINDOW STRIP
ROUND WINDOW
CLEAR
CLEAR
12
LEFT
WING BOTTOM
aSSemBlY
LEFT
FUSELAGE
PILOTS
SEATS -SEMI
GLOSS BLACK
COCKPIT FLOOR
SEMI GLOSS BLACK
paInt nOte FOR
pIlOtS:
GReen -
FlIGHt SUIt
BlacK - SHOeS,
FleSH -
Face and HandS
YellOw -
lIFe JacKetS
Red - capS
10
LEFT
WING TOP
