0 V in "off" condition (each at the terminal with
the number of the channel referring to the com-
mon terminal GND).
On page 3, two circuits of example show
how to use the control voltage for driving a light-
emitting diode (fig. 5) or a 12 V relay (to switch
higher loads, fig. 6).
5.5 Mains connection
Connect the power supply unit provided to the
power supply jack (10) and to a socket (230 V~ /
50 Hz).
6 Preadjustments
The unit must be opened for the following pread-
justments (chapter 6.1 to chapter 6.5).
1) Prior to opening the unit always disconnect
the unit from the power supply!
2) Remove the screws of the housing cover and
the cover.
3) Make the adjustments by means of the slid-
ing switches. The drawings on the last but
one page of these instructions present an
overview over the position of the switches
and their functions described below.
4) After the adjustments have been completed,
fasten the cover and re-establish the power
supply.
6.1 Phantom power
For microphones requiring a phantom power, a
phantom voltage of 12 V (CS-4) or 48 V (CS-8)
may be switched on separately for each input.
For this purpose, set the switch PHANTOM Ⓐ of
the corresponding channel to the position
"+12V" or "+48V".
Important: When connecting microphones or
other signal sources with unbalanced output, the
phantom power must be switched off (position
"OFF") as these units may be damaged.
6.2 Alternatives of connection
(CS-8 only)
For CS-8: It is possible to define in each case for
the channels MIC 1 and MIC 2 if the RCA jack or
the combined XLR / 6.3 mm jack is to serve as an
input. For this purpose set the corresponding
switch Ⓑ to the desired position.
"RCA"= RCA jack
"MIC" = combined XLR / 6.3 mm jack
Important: When using the RCA jack, the phan-
tom power for this input must always be
switched off ( chapter 6.1).
6.3 Input sensitivity
The switch INPUT ATT Ⓒ serves to adjust the
input sensitivity of the respective input to the sig-
nal source used. When connecting a micro-
phone, set the switch to the position "MIC 0 dB",
when connecting a signal source with line output
level, set the switch to position "LINE -50 dB".
The fine adjustment of the sensitivity can be
made in each case with the switch PAD (CS-4)
or MIC IN ATT (CS-8) Ⓓ. Here the level can
additionally be attenuated by 5 dB (CS-8 only) or
10 dB.
6.4 "Off" attenuation
If in the automatic mode a microphone signal is
"locked out" by the signal of another input chan-
nel, the microphone is not completely switched
8
off but its volume is attenuated to a lower value
only.
By means of the switch MIC ATT Ⓔ the
extent of the signal attenuation is defined in the
"Off" condition of each input channel (attenua-
tion by 10, 15 or 20 dB).
If a larger number of microphones is used, it
is recommended to adjust a higher attenuation
to reduce the background noise level and thus to
obtain a better speech intelligibility. Likewise,
with a higher attenuation, the risk of a feedback
is reduced.
6.5 Output level
The output level can be adapted to the input of
the following audio unit with the switch OUTPUT
ATT Ⓕ.
When connecting a microphone input, set
the switch to position "MIC -50 dB". When con-
necting a line input, set the switch to position
"LINE 0 dB".

7 Operation

Prior to the first operation, turn the OUTPUT
LEVEL control (3) to minimum (left stop). Switch
on the microphone mixer with the POWER
switch (9); the LED next to the switch lights up.
The status LEDs (1) of the inputs shortly light up
successively.
7.1 Automatic mode
In the automatic mode, the microphone mixer
switches the microphone channels on and off
depending on the input signals (off = attenuated
chapter 6.4). As soon as the volume of a
microphone exceeds the threshold
adjusted, this channel is switched on while all
other channels remain switched off. As soon as
the volume of the microphone switched on falls
below the threshold value, the microphone may
be replaced by another microphone of corre-
spondingly high volume. Thus, the first micro-
phone is "locked out", one channel only always
remains switched on (exception: channels with
priority chapter 7.1.1).
To establish the automatic mode:
1) Turn the control THRESHOLD (7) so far to
the left that it is not yet engaged. Thus, the
minimum threshold value is adjusted.
2) For the time being set all controls LEVEL (2)
to minimum (left stop) and all PRIORITY
switches (5) to the lower position.
3) Switch on the amplifier system connected to
the output and slightly turn up the OUTPUT
LEVEL control (3) so that the following
adjustments can be heard.
4) Talk into a microphone and turn up the
LEVEL control of the corresponding channel
so that the LED LOCKOUT (6) lights up with
speech at an average volume. This LED indi-
cates that the threshold value adjusted is
exceeded and the microphone channel is
switched on. As long as the channel is
switched on, its status LED (1) lights up.
Turn up the LEVEL control only to such
an extent so that the LED "6" in the indication
MIX LEVEL (4) lights up with signal peaks
only. If it lights up permanently or even the
LED "Peak" (CS-8 only), the mixer is over-
loaded and the output signal is distorted.
If the level is too high or too low to be cor-
rectly adjusted with the LEVEL control, read-
just the adjustment for the input sensitivity, if
required ( chapter 6.3).
5) Adjust the other input channels in the same
way.
6) Adjust the output level of the mixer with the
OUTPUT LEVEL control so that the following
unit will not be overloaded.
7) If microphones are accidentally switched on
by loud background noise, adjust a higher
threshold value with the control THRESH-
OLD.
7.1.1 Priority circuit
If a microphone is to take priority over other
microphones (e. g. the microphone of the chair-
person), set the corresponding PRIORITY
switch (5) to the upper position "ON".
The speaker at this microphone may take
over the conversation at any time. The micro-
phone is switched on as soon as the volume
exceeds the threshold value, regardless of any
other microphone used at this moment.
If priority has been selected for several chan-
nels, these channels can be used at the same
time.
7.1.2 Operating mode of channels 1 and 2
(CS-8 only)
For CS-8, two operating modes are available for
the input channels 1 and 2 by means of the but-
ton MIC 1/2 (8):
"Common" (button engaged, the LED next to the
button lights up):
The signals of both channels are not able to lock
out the other channels, but they are attenuated
as soon as the signal on another channel
exceeds the threshold value. This operating
mode is e. g. suitable for inserting background
value
music.
"Normal" (button disengaged, LED off):
Both channels act like the other channels.
7.2 Manual mixing
If the control THRESHOLD (7) is turned to the
left stop so that it engages in position "BYPASS",
the automatic mixing feature is deactivated. Now
all input channels are switched on. They can
manually be mixed with their LEVEL controls (2).
With the OUTPUT LEVEL control (3), the overall
volume can be adjusted.
For manual mixing, too, the indication MIX
LEVEL (4) should be observed. It shows the
level ahead of the OUTPUT LEVEL control. If
the mixed level is too high (LEDs "6" or "Peak"
light up frequently), the LEVEL controls of the
corresponding channels must be turned back.
7.3 Coupled microphone mixers
If two or several microphone mixers are inter-
connected via the jacks LINK IN (11) and LINK
OUT (13), they act together like a large mixer.
The mixed signals of the complete chain of units
connected via the jack LINK IN are present at
the output MIX OUT (14) of a unit. The mixed
signals are routed in each case ahead of the
OUTPUT LEVEL control (3) so that it is only pos-
sible to adjust the level for the individual output
MIX OUT via this control.
The threshold value for the automatic mode
can be adjusted at each mixer individually for its
inputs. The LED LOCKOUT (6) always lights up
at all units connected when exceeding the
threshold value. If the automatic feature is deac-
tivated at one of the mixers (BYPASS), this does
not affect the automatic feature of the other mix-
ers connected.
