4. Description

4.1 General

FP2
pro/CD/MP3
The EasyPort® FP2
pro/CD/MP3
built-in 4 channel mixer with 2-band equalizer lets you connect a
CD player or similar audio source, two wired microphone, and the
supplied wireless microphone for simultaneous operation. Up to 4
built-in radio receivers are possible.
The FP2 is equipped with an integrated in CD-player.
CD
The EasyPort® is also available with a pre-installed wireless re -
ceiver that provides highly reliable and excellent audio quality. A
handheld or bodypack transmitter of your choice (optional) makes
the EasyPort® a self-contained sound system for use with hardwire
or wireless microphones.
For mains independent operation, the EasyPort® features a built-in
high quality, leakproof lead gel rechargeable battery that conforms
to the strict standards of the German Association of Casualty
Insurers.
The battery features much lower self-discharge and a better
capacity/volume ratio than nickel-cadmium batteries and has no
memory effect.
Battery capacity is 7.2 Ah for the FP2
FP2
slave
Passive additional speaker can be connect to FP2
loadspeaker cable (no integrated electronics).
FP2 are not equipped with a Speakon output port.
pro/CD/MP3
Therefore a speakon output port is delivered with the FP2

4.2 Optional Accessories

FP2 /
pro CD/MP3/slave
• Padded carrying bag for FP2
• Raincover for FP2 /
pro CD/MP3/slave
• SHP2 stand adapter for FP2
• WHP2 wall bracket for FP2
• WHP1 wall bracket for FP2
• Loudspeakerstand
• Microphone stand with boom
• Carrying bag for two stands
• Music-Tray for portable music-playing equipment +
microphone, easy tomount to speaker stands
20 | FP2
are self powered loudspeakers. A
pro/CD.
with
pro/CD/MP3
.
slave
/
pro CD/MP3/slave
,
/
pro CD/MP3/slave
/ provits and tilts
pro CD/MP3/slave,
/ speaker removable
pro CD/MP3/slave,

4.3 Controls

(Refer to illustrations on page 32 to 35)
Most controls on the FP2
pro/CD/MP3
speaker. The squelch control (10) and the channel selector switch
(11) for the radio receiver, which is fitted as an option, are located
under the flap in the cover.
A sturdy carrying handle is integrated in the rear panel of the
enclosure.
(1) recharge battery
Input jack for charging the integrated battery or operating the
EasyPort® on AC power.
(18) fuse
The power fuse is located below the power input socket. Prior
to replacing the power fuse unplug the FP2
power. Make sure to use replacement fuse of the same type as
the original fuse only for 230 VAC:
1 A MTR (5x20mm)
(2) Power pack charge status display
Quick-charge mode, charging time 6 hours
If the yellow LED lights up continuously, the FP2
is in quick-charge mode, the LED then flashes once the power
pack starts charging.
(3) power switch
Switches power to the EasyPort® FP2
and amplifier on and off but does not affect the charging
circuit.
(4) Status display
Status LED, multi-coloured, charge status of the power pack is
indicated by a flashing sequence.
When the FP2 is switched on, the LED lights up
pro/CD/MP3
green if the power pack is fully charged.
When the power pack falls below 30% capacity, the LED starts
to flash red.
If the power pack voltage is decreasing, the LED flashes red
increasingly quickly until it lights up red continuously.
After the LED is lit for 10 seconds, the FP2
off to prevent the power pack from an exhaustive discharge.
A signal sounds when the FP2
(20) DC out jack (12 volt output)
DC out jack, 12V 500mA for connecting external equipment
such as radio receivers and playback devices such as CD
players, etc.
The DC out jack is short-circuit proof and has a polarity
inversion protector.
Note:
The FP2 cannot be charged via this jack.
pro/CD/MP3
are located on the back of the
from
pro/CD/MP3
pro/CD/MP3
audio section
pro/CD/MP3
switches
pro/CD/MP3
switches off.
pro/CD/MP3
