DIAGRAM 1
• Desire the wall position to hang the clock radio.
• Hang the wall bracket by fixing 4 screw with the dowles tightly on wall ( Diagram 2 )
• Put the unti on the bracket and make sure the AC cord and FM antenna is separately outside of bracket.
• Tighten the bracket screw into the bottom of unit ( Diagram 3 )
• Re-check again the all bracket and unit is strongly hanging on the wall.
DIAGRAM 3
020.
Downloaded from www.Manualslib.com
WALLSCREW & DOWLES
WALL BRACKET
manuals search engine
DIAGRAM 2
ARROW ON TOP
SCREW
SCREW
WALL
SCREW
SCREW
