Back-Up Battery; Alarm Setting; Specifications - elta 4248N Gebrauchsanweisung

POWER SOURCE
The unit operates with mains power supply. Clock and alarm with DC back-up, battery: 1 x 9V (not included).
AC POWER SUPPLY
Ensure that the AC power cord is in accordance with your local voltage cord and connect to mains power supply. Press the
POWER button to turn on the unit.

BACK-UP BATTERY

Insert a 9V battery (not included) into the battery compartment located at the bottom; preferably use a long-life battery.
In case of power failure when listening to the radio it will switch off and the display will show a wrong radio frequency,
because the CPU cannot receive any signals from the radio. After the power failure the radio frequency will be restored
to the last frequency and continue working.
RADIO FUNCTION
1. Set the FUNCTION SELECTOR (MODE) to ON.
2. Select desired band with the BAND SELECTOR.
3. Rotate the TUNING control to find your desired radio station.
4. Adjust the VOLUME to a comfortable level.
5. For better reception extend the FM wire antenna to its full length when listening to FM or adjust the direction
6. To switch off the radio set the FUNCTION SELECTOR (MODE) to OFF.
TIME SETTTING
Press and hold the TIME SET button and simultaneously press SLOW SET or FAST SET to skip to the correct time.
Notes:
Press SLOW SET button each time to skip one minute, press and hold the button to skip continuously.
Press and hold FAST SET button to skip fast and continuously.

ALARM SETTING

Note: You can set two different alarm times on this unit.
1. Press and hold either the AL 1 or AL 2 button, then press the SLOW SET/FAST SET button to skip to the desired
2. Set the FUNCTION SELECTOR (MODE) to AUTO.
3. Set the ALARM switch to AL 1 or AL 2 (for one alarm) or AL 1+2 (for two alarms), the corresponding indicator
4. To stop the alarm, slide the FUNCTION SELECTOR (MODE) to OFF or press AL OFF.
SLEEP FUNCTION
To switch off the radio automatically after 59 minutes slide the FUNCTION SELECTOR (MODE) to AUTO and press SLEEP.
After 59 minutes the radio will switch off automatically.
At the preset alarm time you will be woken by radio.

SPECIFICATIONS

Power supply
Power consumption
Operating temperature
Receiving Bands
Tuning Range
Speaker impedance
NET WEIGHT:
Specifications are subject to change without prior notice.
Downloaded from www.Manualslib.com
when receiving AM.
alarm time.
will illuminate.
At the preset alarm time the alarm will set on the radio automatically. To pause the alarm and sleep another 9 minutes
press the SNOOZE button.
230V~ 50Hz
(check the rated power on rating plate at the bottom of the device)
Back-up 9V DC
3W
+5ºC - +35ºC
AM/FM
AM: 525 - 1615kHz
FM: 87.5 - 108MHz
8Ω
537g
