QUICKSTART GUIDE
Make sure that the items listed below are included in the box:
o
PROFILE FLASH Turntable
45 RPM Adapter
Safety Instructions & Warranty Information
READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE PRODUCT
o
Go to http://www.ionaudio.com for product registration.
o
REAR PANEL FEATURES
1.
POWER CABLE – This power cable
should be plugged into a wall receptacle
AFTER all audio connections are made.
2.
POWER ON / OFF SWITCH – Turns
PROFILE FLASH on or off.
3.
RCA AUDIO OUTPUT CABLES –
These cables should be plugged into the audio inputs of your home stereo system. (Please note: you can still
copy records to your USB device or SD card, even if the audio outputs of the turntable are not connected to a
stereo system).
4.
AUDIO INPUT – Connect a tape player, reel-to-reel machine, or other audio source to this input using a 1/8"
stereo cable. Any signal entering this input will be included in the playback or recording mix.
TOP PANEL FEATURES
1.
PLATTER – This platter must be
securely fastened to the turntable prior
to operation. The Motor Drive Belt can
be found on the drive ring underneath
the platter.
2.
45 RPM ADAPTER HOLDER – Holds
the included 45 RPM adapter.
not using the adapter, please place it in
this holder.
3.
TONEARM – PROFILE FLASH comes
with a ready to use pre-balanced
TONEARM
and
TONEARM can be raised and lowered
by hand, or by pressing the RAISE /
LOWER LEVER. Please note that the
TONEARM needs to be moved away
from resting position (on the ARM CLIP)
for the turntable motor to activate.
When the TONEARM is placed back in
its resting position, the turntable motor
will deactivate.
4.
ARM CLIP – This specially designed arm clip secures the
tone arm while at rest or when not in use. The arm clip has
been designed to remain in the up position while unlocked.
5.
RAISE / LOWER LEVER – Raises and lowers the tonearm.
Slipmat
Quickstart Guide
When
cartridge.
The
4
3
2
1
IMPORTANT
Make sure that the slipmat is always
placed on top of the platter while using the
turntable. Failure to use the slipmat may
cause damage to your media as well as
damage to the turntable.
Remove the plastic cartridge cover (needle
cover) before operating the turntable.
1
2
1
5
3
4
