Adjusting pad effect
1.
Use the direction key
2.
press [SET UP] to enter pad effect setting interface
EQ setting
3.
Use the direction key
4.
Use the direction key
(
HI GAIN=13 default
(
MID GAIN=15 default
(
LOW GAIN=18 default
Ambience setting
5.
Use the direction key
6.
Use the direction key
AMBIENCE=OFF
AMBIENCE=01
AMBIENCE=02
(
when adjusting parameters, press [SET UP] button
to reset all parameters to the default status

MIDI setting

This device is compatible with various MIDI devices. When used as trigger device or audio
source, it is compatible with GM standard, and can be used with many sequencer software

MIDI connection

MIDI IN: inputs MIDI signal when connecting with external MIDI device.
MIDI OUT outputs MIDI signal when connecting with external MIDI device.
USB: standard USB2.0 interface connect with USB of MIDI device or PC. The operation
system has relative driver without the need to install again. Compatible with the PC system,
e.g. Xp Win7,Vista,Mac OSX . After connection, the system recognizes this device as USB
.(
AUDIO DEVICE (USB only used for MIDI connection
Note: when USB connects with PC, all MIDI data can transfer via USB
to switch to EFFECT
to select EQ type.
to change EQ value.
)
Range :01---25
)
Range :01---25
)
Range :01---25
to select AMBIENCE
to switch ambience effect
DRUM PAD SETTING
PAD SENSITIVITY
RELOAD FAC SET
EFFECT
HI GAIN=13
MID GAIN=15
MID GAIN=18
AMBIENCE=OFF
HI GAIN=13
)
MID GAIN=15
MID GAIN=18
AMBIENCE=OFF
)
