1 Produkteigenschaften
1.1 Technische Daten
Spannung: 100 - 240 VAC 50/60 Hz
Max Power: 350 W
Abmessungen : 338 x 270 x 341 mm
Gewicht: 10 kg
1.2 Features
Head
Side arm
Up
Menu
Down
Enter
DMX 3-PIN signal output
Switch
Fuse holder
DMX 5-PIN signal output
DMX 5-PIN signal input
Power OUT DMX 3-PIN signal input
Power input
D 02
CHANNEL FUNCTION VALUE
11
RED 000 255 RED
12 000 255
FINE RED FINE RED
13 000 255
GREEN GREEN
14
FINE GREEN 000 255 FINE GREEN
15
BLUE 000 255 BLUE
16 000 255
FINE BLUE FINE BLUE
17 000 255
WHITE WHITE
18
000 255
FINE WHITE FINE WHITE
19 000 255
U RED U RED
20 000 255
UFINE RED UFINE RED
000 255
21
U GREEN U GREEN
22 000 255
U FINE GREEN U FINE GREEN
23 000 255
U BLUE U BLUE
24
U FINE BLUE 000 255 U FINE BLUE
25 000 255
U WHITE U WHITE
26 000 255
U FINE WHITE U FINE WHITE
27
RED٢D 000 255 RED٢D
28 D FINE RED 000 255 D FINE RED
29 GREEN٢D 000 255 GREEN٢D
30 D FINE GREEN D FINE GREEN
000 255
BLUE٢D BLUE٢D
31 000 255
D FINE BLUE D FINE BLUE
32
000 255
WHITE٢D WHITE٢D
33 000 255
D FINE WHITE D FINE WHITE
34 000 255
EFFECT
E 23
