Information concerning the operating manual

1 Information concerning the operating manual
This operating manual is an important aid for ensuring the safe and reliable functioning of the tank. Reflex Winkelmann GmbH accepts no liability for any
damage resulting from failure to observe the information in this operating manual. In addition national statutory regulations and provisions in the
country of installation must also be complied with (concerning accident prevention, environment protection, safe and professional work practices, etc.).
2

Safety

2.1

Personnel requirements

The assembly of, connection of and structural alteration work to the tank must be carried out by an authorised specialist company in accordance with all
applicable national and local regulations.
2.2

Intended use

The buffer tank must only be used in closed heating and/or chilling systems.
Intended use comprises the following points:
- Only static and fixed installation
- Adherence to the installation, operating and maintenance conditions
- Not to be installed outside
- Filling of the buffer tank must take place using heating water according to VDI Guideline 2035 Sheet 1 and 2.
2.3

Impermissible operating conditions

The tank is not suitable for the following conditions:
- Operation below the dew point as the insulation is not diffusion-tight. In this case the tank must be insulated so that it is diffusion-tight.
- Operation outside the maximum operating conditions.
- Ensure that the connections are made in a zero-volts state.
- Implement suitable measures to prevent frost damage.
3

Description

The buffer tank acts as an intermediate store for heating water for further transport to the heating circuit.
3.1

Identification

The nameplate provides information on manufacturer, year of manufacture, part number and technical data. The nameplate is located on the tank or the
tank insulation.
3.2

Regulations

All applicable national and local regulations and directives must be adhered to during installation, operation and maintenance.
4

Technical data

Note!
The following values apply for all buffer tanks:
• Manufacturing or serial number
• Year of manufacturing
• Nominal tank volume in litres
• Maximum working pressure
–
–
• Height in mm
• Diameter in mm
• Blanking flange in DN
• Max. tank operating temperature
• Number of system connections
• Number of sensors, emptying connections
4 — English
up to 1000 L
greater than 1000 L
Storatherm — 06.04.2018
See nameplate
See nameplate
See nameplate
See nameplate
3 bar
6 bar
See technical data
See technical data
See technical data
95°C
9
3
