2. Song number, level meter, page title
While stopped
During playback
During recording or in
Record Ready mode
In Menu mode
3. Counter, parameter
During record‐
ing or playback
In Menu mode Indicates the parameter option or value in the page
4. Battery indicator
The battery indicator shows the amount of battery power.
High
If
is flashing, the batteries are almost exhausted. Replace them
immediately.
The battery indicator does not appear while you are using an
optional AC adapter.
5. Song position bar, tuning meter, touch slider
During
Song position bar
Indicates the current playback position. You can change
playback
the playback position by using this bar as a touch slider.
During
Tuning meter
Indicates the current tuning status. If your instrument is tuned
tuner
correctly, the bar graph will reach and stop at the center.
operation
Effect
Touch slider
Enables you to adjust the parameter value by touching the slider.
Select page
Rhythm
Touch slider
Enables you to select a rhythm variation by touching the slider.
Select page
Other
Touch slider
If a frame is displayed around the bar, you can touch
parameters
inside the frame to change parameter values.
Indicates the song number
Indicates the playback level meter
Indicates the input level meter
Indicates a page title in the category
Indicates the current playback position
HMS Indicates the current position in hour, min‐
ute, second
MBQ Indicates the current position in measure,
beat, quarter‐beat
Low
13
