KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Montageanleitung Stativ Assembly instructions Tripod Instructions de montage Statif KERN EOB-A01-A01N Version 1.0 03/2013 EOB-A01 EOB-A01N EOB-A01-A01N-IA-def-1310...
Seite 2
Weitere Sprachversionen finden Sie online unter www.kern-sohn.com/manuals Další jazykové verze najdete na webu pod adresou www.kern-sohn.com/manuals Yderligere sprogversioner finder de online på www.kern-sohn.com/manuals Más versiones de idiomas se encuentran online bajowww.kern-sohn.com/manuals Rohkem keeli internetis aadressil www.kern-sohn.com/manuals Vous trouverez d’autres versions de langue online sous www.kern-sohn.com/manuals Further language versions you will find online under www.kern-sohn.com/manuals A használati utasítás egyéb nyelveken a www.kern-sohn.com/manuals címről tölthető...
Anzeigegerät mit den Drehknöpfen positionieren. 4 Montage EOB-A01N 4.1 Stativ an Waage montieren Stativ lt. Abbildung mit den 4 Schrauben an der Unterseite der Plattform befestigen. Darauf achten, dass beim festschrauben nicht zuviel Druck auf die Wägeplatte gerät. EOB-A01-A01N-IA-d-1310...
Öffnung an der Unterseite des Stativs einpassen. Stützschraube so weit herausdrehen, bis die Waage stabil und waagrecht steht. 4.2 Anzeigegerät an Stativ montieren Anzeigegerät mit den beiden schwarzen Drehknöpfen lt. Abbildung am Stativ befestigen. Anzeigegerät mit den Drehknöpfen positionieren. EOB-A01-A01N-IA-d-1310...
Assembly instructions Tripod Contents Technical data ......................2 Scope of delivery ....................3 Assembly EOB-A01 ....................3 Assemble the tripod to the balance ................. 3 Assemble the display unit to the tripod ................4 Assembly EOB-A01N ....................4 Assemble the tripod to the balance ................. 4 Assemble the display unit to the tripod ................
3. Turning knobs for assembly display unit 4. Support screw (already assembled) Support screw 5. Rubber cover 3 Assembly EOB-A01 3.1 Assemble the tripod to the balance Example: Fasten the tripod acc. to illustration with the 4 screws on the lower side of the platform.
4.1 Assemble the tripod to the balance Fasten the tripod acc. to illustration with the 4 screws on the lower side of the platform. Observe that during screwing down not too much pressure is performed on the weighing pan. EOB-A01-A01N-IA-e-1310...
4.2 Assemble the display unit to the tripod Secure the display unit with the two black rotary knobs to the tripod according to illustration. Position display unit with the rotary knobs. EOB-A01-A01N-IA-e-1310...
Instructions de montage Statif Table des matières Caractéristiques techniques ................... 2 Etendue de la livraison .................... 3 Montage EOB-A01 ....................3 Monter le statif à la balance ....................3 Monter l’afficheur au statif ....................4 Montage EOB-A01N ....................4 Monter le statif à la balance ....................4 Monter l’afficheur au statif ....................
Vis d’appui 4. Vis d’appui (déjà montée) 5. Couverture en caoutchouc 3 Montage EOB-A01 3.1 Monter le statif à la balance Exemple: Fixer le statif selon l’illustration à l’aide des quatre vis au côté inférieur de la plateforme.
4.1 Monter le statif à la balance Fixer le statif selon l’illustration à l’aide des quatre vis au côté inférieur de la plateforme. Veiller à ce que en serrant à fond pas trop de pression ne soit exercée sur le plateau de pesée. EOB-A01-A01N-IA-f-1310...
Dévisser la vis d’appui jusqu’à ce que la balance soit en position stable et horizontale. 4.2 Monter l’afficheur au statif Fixez l’afficheur par les deux boutons tournants noirs au statif selon l’illustration. Positionnez l’afficheur au moyen des boutons tournants EOB-A01-A01N-IA-f-1310...
