Owner's manual
(1) wind direction and/or velocity, include high gusts of wind.. Heavy air in
vent pipes(cold/humid air with extended periods between cycles).
(2) Negative pressure differential resulting from the use of exhaust fans.
(3) Simultaneous operation of several fuel burning appliances competing for
limited internal air.
(4) Vent pipe connections vibrating loose from clothes dryers furnaces or
water heaters.
(5) Obstructions in or unconventional vent pipe designs which can
amplify the above situation. Extended operation of unwanted fuel burning
devices(range, oven, fireplace, etc).
Temperature inversions which can trap exhaust gasses near the ground. Car
idling in can open or close attached garage, or near a home.
5.INSTALL YOUR ALARM
Our CO alarm is to be mounted on the ceiling or on the wall if necessary.
Since our CO alarm is a signal-station type, it can not linked to the other
alarms.
Please follow these steps to install your CO alarm
1. Remove the mount bracket from your unit.
2. Place the bracket on wall. In each of keyhole slots,
draw a mark to locate a mounting plug and screw.
3. Remove the bracket.
4. Using a 3/16-inch(5mm) drill bit, drills two
holes at the marks and insert plastic wall plugs.
5. Line up the slot of the bracket and the alarm.
Push the alarm onto the mounting bracket and plugs
down.
6. Power on AC power.
NOTE: when the alarm power on first ,the alarm horn may sound one time.
The green led will on away. This means normal and indicates that the power
on correctly. The alarm may take one minute to warm up, then press the
button. The horn should be sound a loud pulsating alarm. This mean the
alarm is working properly.
EN
13
