P X - iP
Quick Reference Guide
The Quick Reference Guide is not a substitute for the operating
manual. It is essential to read and observe the operating manual.
It is available at:
www.pyrexx.com/de/support/download
Pay special attention to the included safety instructions and
information on the use and operation of the gateway and the
smoke alarm devices.
1 Notes and
IMPORTANT:
Only press the buttons to the point
requirements
that you feel a resistance, and keep
them pressed in that position.
1.1 Notes on commissioning
1
2
3
The Quick Reference Guide describes
initial installation of the gateway in com-
bination with smoke alarm devices from
the web app.
It is essential that you follow the
action steps in the order given for a
successful installation
For other installation types, trou-
bleshooting, etc., see the operating
Fig. 1
Gateway controls
manual for the gateway and/or
1
Battery compartment
smoke alarm devices
2
Radio button (A) with signal LED
Observe the notes in the web app
3
Gateway button (B) with signal LED
Only use the power unit and
4
Port for power unit
power cable included in the shipping
package
5
LAN port
Remove the protective fi lm from the
3 Commissioning
plug and gateway
1.2 Requirements for commissioning
Open the web app in the browser at
www.pyrexx.com/app
Prior to commissioning, ensure the follow-
ing at the installation location:
3.1 Registering as a user
•
Internet connection
If you do not have access to the web app yet,
set up your user account fi rst.
•
Router with LAN connection
LAN or WI-FI connection
(1) Enter the registration details
•
For WI-FI:
In the web app's start-up screen, click
•
WLAN-SSID (WI-FI name), password
"Register"
and encryption type must be available
Enter your personal details and choose
a password
•
At least one PX-1C
smoke alarm device
The email address will be your
user name. Your residential address
Gateway in default state
•
(see „4.1 Gateway reset")
and name will be used in the
notifi cations. You can also just enter
End device for web app operation:
•
"x" there, for example.
smartphone, tablet or PC with
Internet browser
Optionally check the "Create an
apartment for this address" check box
2 Controls
Check the "I accept the terms and
conditions of use" check box
The gateway is controlled via buttons with
Click "Complete registration"
signal LEDs. You must be able to see the
light signals, even when the buttons are
activated.
Version of the Quick Reference Guide 2016-04
Gateway
(2) Confi rm the registration process in
"Gateway" is shown as the type and
"Pyrexx" as the manufacturer
the email
Enter the verifi cation code on the
Registration successful
name plate of your gateway
3.2 Log-in
Click "Save"
In the start-up screen, enter user
Gateway icon appears in the room
name and password
sketch
Click "Log in"
3.4 Gateway setup
Web app log-in successful
(1) Click the gateway icon
3.3 Adding gateway in the
(2) Click "Radio group" title, then click
apartment
"Gateway functions" button
4
5
In the main menu
, select
You are now in the "Gateway func-
"Apartments" entry
tions" menu
Select created apartment
(3) Set up gateway
(1) Click apartment
Click "Set up gateway" and observe
(2) Click "Devices" title, then click
notes
"Rooms" button
Click "Continue"
Room list appears
(4) Even if you want to set up a WI-FI
connection, connect the gateway to
the router using a LAN cable
(5) Select LAN or WI-FI connection
For a more stable installation, we
recommend a LAN connection.
For a WI-FI connection enter the
Adding a new apartment
WI-FI parameters and click "Save"
Only required if you did not check the
"Create an apartment for this address"
3.5 Connecting the gateway
check box during registration.
(1) Connect plug with power cable and
(1) Click "New apartment"
plug into power outlet
(2) Connect power cable with gateway
"New apartment" screen opens
(3) As soon as the signal LED of the
(2) Enter address and tenant details
gateway button (B) starts fl ashing
(3) For "Type" select "Apartment" or
click "Establish connection"
"Detached house" (multiple levels)
Message: "The connection attempt is
(4) Click "Save"
running. This process can take up to
Apartment has been created
3 minutes. "
Room list appears
While the gateway is starting up the
LEDs of the gateway button (B) and
Adding a gateway
the radio button (A) become active
(1) Click the room in which you wish to
in that order.
install the gateway
Gateway starts:
Room sketch appears
(2) Add gateway
Gateway parameter query:
Click "Add a device"
Enter the serial number on the name
plate of your gateway
Normal operation:
(B)
Gateway is connected with the router
Radio group query:
(A)
(A)
No radio group found in learning
mode
Message: "The connection attempt
was successful"
(4) Click "Installation complete"
You are back in the room sketch
3.6 Creating a radio group with
gateway and smoke alarm
devices
The connection between smoke alarm
devices and the gateway is set up di-
rectly on the devices (learning mode).
(1) For WI-FI connection now remove
the LAN cable and bring the gateway
to the planned installation site
(2) Press radio button (A) on the
gateway until signal LED is on, then
release:
(A)
Starting learning mode on the gateway:
(A)
(A)
(A)
Gateway is in the learning mode for
10 minutes max.
Adding a smoke alarm device to a
radio group
IMPORTANT:
a) Do not activate any smoke alarm
device until it is at the intended
installation location.
b) Ensure a minimum distance of
(B)
3 m to the other smoke alarm
devices and the gateway.
(B)
3.7 Network scan
1
(1) Click the gateway icon
2
(2) Click "Radio group" title, then click
"Gateway functions" button
3
(3) Click "Scan network"
4
Message: "Network scan in progress"
(4) Wait until network scan has
5
completed
6
(5) Click "Network scan complete"
In the case of an error consult the
7
operating manual
(6) Click "Gateway functions" title, then
Fig. 2
Smoke alarm device controls
click "Radio group" button
1
Split pin (activation backup)
2
Activation button
You are now in the "Radio group"
menu
3
Magnetic carrier
4
Signal LED
Assigning smoke alarm devices to rooms
5
Radio button
Assign each smoke alarm device the
6
Smoke intake lamellas
correct room
7
Test/Stop button
(smoke alarm device cover)
Smoke alarm devices have been
assigned to the rooms
(1) Remove split pin at the red activation
3.8 Test signal and measured data
button of the smoke alarm device
(1) Click
to go back to the room
(2) Push activation button fl ush
sketch menu
Short acoustic signal
(2) Click the gateway icon
(3) Click "Radio group" title, then click
Starting learning mode on the smoke
"Gateway functions" button
alarm device:
(4) Click "Trigger test signal"
Message: "Test signal in progress"
Short acoustic signal from all
installed smoke alarm devices
Radio group in learning mode for
(5) Click "Test signal complete"
another 10 minutes
(6) To view the measured data of
(3) Switch all other smoke alarm devices
a smoke alarm device, click the
into learning mode as described
smoke alarm device in the "Radio
(4) Finalise radio group
group"menu
Briefl y press fl ashing radio button (A)
(7) Click "Maintenance" title, then click
on the gateway until light goes off
"Measured data" button
Radio group is in operation
Measured data of the smoke alarm
device is displayed
No device in the radio group is
fl ashing
© Pyrexx Technologies GmbH
4 Reset
4.1 Gateway reset
Prior to the reset, the gateway must be
connected to the power supply.
(1) Start reset
Remove power cable on the gateway
Cyclic acoustic signal on the
gateway for 30 seconds
(B)
During this time, the following steps
must be performed in that sequence:
(2) Reset radio module
Press radio button (A) on the gate-
way until it fl ashes, then release
(A)
(A)
Signal LED of radio button (A)
OFF
(3) Reset network
Press gateway button (B) until a long
acoustic signal is emitted, then release
(B)
Gateway is turned off
4.2 Smoke alarm device reset
In order to re-create the radio group
after the gateway reset, also reset the
smoke alarm devices.
(1) Pull out activation button
(2) Press and hold Test/Stop button for
about 2 to 3 seconds
Soft ticking for about
2 seconds
(3) Press radio button with splint pin
until it fl ashes, then release
The device is in its default state
