User manual / Bedienungsanleitung
2. Technical data
Amplification:
Input load:
MM / MC - input:
RIAA:
RIAA accuracy:
THD:
S/N:
Channel separation:
Max. output voltage:
Subsonic filter:
Power supply:
Outputs:
Total power consumption:
Total power max.:
Off mode:
Weight:
Dimensions Phono ( w x d x h ):
Dimensions Power Supply ( w x d x h ):

Warranty:

* Provided that the warranty card is correctly completed and returned to Clearaudio within 14 days of purchase.
Clearaudio electronic is not responsible for typographical errors in descriptions.
Technical specifications subject to change or improvement without prior notice.
Product availability is as long as stock lasts.
Copies and reprints of this documents, including extracts, require written consent from
Clearaudio electronic GmbH; Germany
Made in Germany
44dB (MM mode )
63dB (MC mode )
47 kOhm / 220pF MM
510 Ohm / 220pF MC
Switchable (on bottom panel)
Nach RIAA
(delay time / Zeitkonst: 75µs / 318µs / 3180µs)
± 0.1dB
0.001% (IEC A):
- 89db MM mode
- 74db MC mode
> 92dB @ 1 kHz
10.5V @ 1 kHz
20Hz: –3dB / Oct
± 18 V DC external power supply
unbalanced / (RCA)
balanced / (XLR)
6.6 watts
6.6 watts
0 watts (turned off at rear panel)
approx. 2.5 kg power supply
approx. 1.8 kg preamplifier
7.09 x 8.66 x 2.17 inches
180 x 220 x 55mm
7.09 x 7.28 x 2.17 inches
180 x 185 x 55mm
3 years*
