User manual / Bedienungsanleitung

1. Setting up operation

To ensure the best possible channel separation the left and right channels are entirely separate in
this design.
Therefore all switches are duplicated for the left and right channels. Please make sure that both
corresponding switches are always in the same position. To change the small inset set-up switches
use the tip of a ball-point pen or similar device.
Select cartridge type operation mode:
Set the switches on the bottom panel of the
• MM operation: Both buttons 'load' & 'gain' not pressed in (load impedance = 47 kOhm)
• MC operation: Both buttons 'load' & 'gain' pressed in (load impedance = 510 Ohm)
Select input mode between unbalanced and balanced operation:
Set the switches on the bottom panel of the
• balanced / symmetrical operation: Both buttons not pressed in
(use balanced XLR interconnects for input and output)
• Unbalanced / unsymmetrical operation: Both buttons pressed in
(use unbalanced RCA / cinch interconnects for input and output)

Subsonic-Filter:

Set the switches on the bottom panel of the
• Subsonic filter is on: Both buttons 'subsonic' pressed in
• Subsonic filter is off: Both buttons 'subsonic' not pressed in
Please note:
Before switching any settings be sure to shut off the power to the
switch on the rear panel of the power supply.
Mute function:
The button marked 'mute' on the front panel switches off the musical signal. A blue light above the
switch shows that the mute function is activated.
Variable function:
The button marked 'variable' on the front panel activates / deactivates the volume control.
A blue light above the switch shows that volume knob will adjust the output level.
When the light is not lit the variable volume is bypassed and the
through a volume-controlled preamplifier!
To prevent your loudspeaker from any damage please make sure that your power
amplifier(s) are always switched off when you are connecting the interconnects to or
balance+
from the phono-preamplifier!
Made in Germany
balance+
chassis as follows:
balance+
chassis as follows:
balance+
chassis as follows:
balance+
using the
balance+
must be fed
3
