Your indoor station for
hands-free talking
Ring tone OFF
button with status
display (red LED is on)
Speech button
voice cannel by
Light switch
flashing green LED
button
Control key
Volume control
for ring tone and voice
Green LED is ON
incoming door-, flat-door or internal calls
active voice communication
blinks 3 times
busy voice channel,
door release can still be realised
Red LED is ON
ring tone OFF is activated,
Both LED are ON
ring tone selection is activated
flash continuously
error indication
The device is not ready for operation.
Error has to be fixed by a qualified electrician.
Handling
The bell rings
A ring tone signals an incoming
Light switching
call from front-door, flat-door or
Press the light switch button.
an internal call.
The green LED is ON.
Ring tone mute
Press the ring tone OFF button.
Start a voice communication
An incoming call will not be
Press the speech button shortly
signalled acoustically.
to accept calls.
The green LED is ON.
To end ring tone mute press the
The green LED blinks 3 times,
ring tone OFF button again.
Red LED
if a voice communication
Green LED
already exists. Door release
can still be realised.
Additional call and switching
signals busy
functions can be added to
the indoor station.
Terminate the
For more information refer
Door release
voice communication
to www.tcsag.de.
button
Press the speech button again
shortly ( less than 1 second ) or
TIP
the blue door release button
Should background noise
ends the communication.
affect the communication,
Automatic termination of voice
press the speech button
communication after at least 2
more than 1 second after
having accepted the call in
minutes.
order to switch to the mode
„half-duplex communication".
Door release
Press the blue colored door
In this mode the voice
release button.
communication is controlled
by the speech button:
to talk.
to listen.
Link to PDF download
Configuration
Ring tone selection
Different ring tones can be
selected for different incoming
calls (e.g. front-door calls, flat-
door calls, internal calls). Please
proceed as follows:
1. Activate ring tone selection
Terminate voice communication.
The red LED is ON.
Press the ring tone OFF button
, hold it for 8 seconds.
An acknowledegement tone
The red LED is OFF.
sounds.
Both LEDs are ON.
The ring tone selection is
activated.
2. Select ring tone
a) for front-door call
Press the door release button
until the desired ring
tone sounds.
b) for flat-door call
Press the light switch button
until the desired ring
tone sounds.
c) for internal call
Press the control key
until the desired ring tone
sounds.
Hold the speech button
The ring tone selected last
will be stored.
Release the speech button
Reinigung
Reinigen Sie das Türtelefon mit
einem trockenen oder ange-
feuchteten Tuch. Stärkere Ver-
schmutzungen entfernen Sie mit
Haushalts-Kunststoffreiniger.
3. Deactivate
ring tone selection
Vermeiden Sie das Eindringen
Press the ring tone OFF button
von Wasser in das Gerät! Ver-
shortly. If no button has
wenden Sie keine aggressiven
been pressed for 8 seconds, the
und kratzenden Reinigungs-
device automatically ends the
mittel!
ring tone selection.
An acknowledegement tone
Service
sounds.
Both LEDs are OFF.
Adjust the volume
Die Gewährleistung erfolgt
The volume of the ring tone
entsprechend den gesetzlichen
resp. of the voice can be ad-
Bestimmungen.
justed in 8 steps by turning the
Der Austausch des Gerätes
volume control to the right
im Fehlerfall muss durch Ihren
(louder) or to the left (lower).
Elektrofachmann erfolgen.
Ring tone volume
if no
voice communication exists
Entsorgung
Voice volume at the indoor
station
if a voice communi-
Die Geräte, gekenn-
cation already exists
zeichnet mit neben-
stehendem Symbol,
sind getrennt vom
lower
louder
Hausmüll zu entsor-
gen. Die verwendeten Materi-
ANNOUNCEMENT
alien sind recyclebar. Bitte leisten
FUNCTION
Sie einen Beitrag zum Schutz
This indoor station is
unserer Umwelt und entsorgen
suitable for the transmission
Sie das Gerät über eine Sammel-
of announcements.
stelle für Elektronikschrott.
A loud tone signals the
announcement. Please
observe that in this case,
TCS TürControlSysteme AG
Geschwister-Scholl-Straße 7
user individual settings such
39307 Genthin
as volume resp. ring tone
Germany
mute become ineffective!
www.tcsag.de
Cleaning
Clean the door telephone using
a dry or slightly moist cloth.
Remove stronger stains with a
mild household cleaner.
Avoid water entering the
device! Do not use any
aggressive or abrasive
cleaning agents!
Service
The legal regulations are
applicable in case of warranty.
The replacement of the device
in the fault case has to be
carried out by your qualified
electrician.
Disposal
The adjoining symbol
shows, that the de-
vice has to be dispo-
sed separately from
domestic waste. The
materials used are recycable.
Please do help protecting out
environment and dispose the
device via a collection point for
electronic scrap.
Service
hotline@tcsag.de
Technische Änderungen vorbehalten.
Rights to technical modifications reserved.
Art.-Nr. 0034170
Version 3 A
