1. Introduction 1.6 Ready to use
GB
Thank you very much for purchasing one of our products. Before opera- The logger is already preset (see 5 default settings) and ready for start. It can be used
ting the data logger please read this manual carefully. You will get useful immediately without any software!
information for understanding all functions.
2. First Start & Begin Recording
1.1 Delivery contents
Press button for 2 seconds,
• Data logger LOG32 • Wall holder • Battery 3,6 Volt
beeper sounds for 1 second
• USB protection cap • 2x screws and dowels (already inserted)
1.2 General advice
• Check if the contents of the package is umdamaged and complete.
• Remove the protection foil above the start button and the two LEDs.
• For cleaning the instrument please do not use an abrasive cleaner only a dry or
wet piece of soft cloth. Do not allow any liquid to the interior of the device.
• Please store the measuring instrument in a dry and clean place.
LED lights green for 2 sconds - logging
• Avoid any force like shocks or pressure to the instrument.
has started!
• No responsibility is taken for irregular or incomplete measuring values and their
results, the liability for subsequent damages is excluded!
see Fig.A
1.3 Overview
1. Start button, 2. LED green, 3. LED red, 4. battery case, 5. USB-connector, 6. USB-
cover, 7. wall holder, 8. Slits ... this is where the sensor is located, 9. protective foil
1.4 Scope of delivery and usage
LED blinks green every 30 sec.
LOG32TH/LOG32T/LOG32THP series loggers are suitable for recording, alarm
tracking, and display of temperature, humidity*, dew point* (*only LOG32TH/THP) and
barometric pressure (only LOG32THP) measurements. Areas of application include
the monitoring of storage and transport conditions or other temperature, moisture
and / or pressure-sensitive processes. The logger has a built-in USB port can be
connected without cables to all Windows PCs. The USB port is protected by a
transparent plastic cap. The green LED flashes every 30 seconds during recording.
2.1 Restart recording
The red LED is used to display limit alarms or status messages (battery change ...
see 2. The logger is started by default by button and stopped by USB port plug-in.
etc.). The logger also has an internal buzzer that supports the user interface.
The measured values are plotted automatically to the PDF file.
NOTE: When you restart the existing PDF file is overwritten.
1.5 For your safety
Important! Always secure the generated PDF files on your PC.
This product is exclusively intended for the field of application described above.
It should only be used as described within these instructions.
Unauthorized repairs, modifications or changes to the product are prohibited.
3. Stop recording / Create PDF
4. Description of PDF result file (see Fig. B)
Connect logger to USB port. Filename: e.g.
Beeper sounds for 1 second. LOG32TH_14010001_2014_06_12T092900.DBF
LED blinks green until result PDF is
LOG32TH: Device
created (can take up to 40 seconds). A
14010001: Serial
2014_06_12: Start of recording (date)
T092900: time: (hhmmss)
B Description: Log run info, edit with LogConnect* software
Beeper sounds and LED stays green.
C Configuration: preset parameters
Logger is shown as removeable drive
LOG32TH/LOG32T/ LOG32THP.
D Summary: Overview of measurement results
E Graphics: Diagram of measured values
F Signature: Sign PDF if required
X
G
:Measurement OK :Measurement failed
View PDF and save.
PDF will be overwritten with next 5. Standard settings / Factory settings
log start! Note the following default settings of the data logger before first use. By using the
LogConnect* software, the setting parameter can easily be changed:
Interval: 5 min. LOG32TH/ LOG32THP, 15 min. LOG32T
Start possible by: Key press
Stop possible by: USB connect
Low Alarm:
Temperature: -40,0°C
Humidity (LOG32TH/ LOG32THP): 0,0 %rH
Pressure only LOG32THP: 300 hPa
Alarm delay: 0 s
* LogConnect download link to access the software
http://download.dostmann-service.de , select
Downloads/Software/5005-0172_Log32TH/Software/
Logger in standby mode (not in record mode)
6. Battery replacement
Twist rear cap (about 10°),
the battery lid opens.
Remove empty battery and insert
new battery like shown.
Battery change ok:
* LogConnect download link to access the software
both LEDs light for 1second, beep sounds.
http://download.dostmann-service.de , select
Downloads/Software/5005-0172_Log32TH/Software/
8. Waste disposal
This product has been manufactured using high-grade materials and components which can
be recycled and reused.
NOTE: Check Logger status: Press start button for appr. 1 second. If the green Never dispose of empty batteries and rechargeable batteries in household waste.
LED flashes twice the logger is recording! This procedure can be done as often as As a consumer, you are legally required to take them to your retail store or to an
High Alarm:
you want. appropriate collection site depending on national or local regulations in order to
70,0°C protect the environment. The symbols for the heavy metals contained are:
7. Alarm signals
100,0 %rH Cd=cadmium, Hg=mercury, Pb=lead
1100 hPa Logger in record mode
This instrument is labelled in accordance with the EU Waste Electrical and
Beeper sounds once each 30 seconds for
Electronic Equipment Directive (WEEE). Please do not dispose of this instrument in
1 second, red LED blinks ach
household waste. The user is obligated to take end-of-life devices to a designated
3 seconds - measured values exceeds
collection point for the disposal of electrical and electronic equipment, in order to
selected measurement range
ensure environmentally-compatible disposal
(not with standard settings).
This sign certifies that the product meets the requirements of the EEC directive and
Alarm limits can be changed using
has been tested according to the specified test methods.
LogConnect* software.
Technical changes, any errors and misprints reserved. Stand01_CHB1504
Logger in standby mode (not in record mode)
Red LED blinks once each 4 seconds.
Replace battery.
LOG32TH / LOG32T /
LOG32THP
5005-0172 / 5005-0170 / 5005-0173
Red LED blinks twice or more
each 4 sconds. Hardware fault!
Datenlogger für Temperatur, Feuchte* und Druck**
Data logger for temperature, humidity* and pressure**
*nur LOG32TH/LOG32THP
*only LOG32TH/LOG32THP
Bedienungsanleitung
**nur LOG32THP
Operating Instructions
**only LOG32THP
