Button functions
Button
Function
Left button
Select, click; confirm; configure on operating system
Right button
Open menu; configure on operating system
Scroll wheel
Scroll; configure on operating system
Next page in web browser
Previous page in web browser
Reducing power consumption
• The mouse has an on/off switch (7) (the on/off switch is hidden in the product diagram).
• To increase the battery life, switch off the mouse when it is not in use (slide the switch to the
OFF position).
• Switch the mouse back on when you need to use it (slide the switch to the ON position).
• The mouse switches to standby mode after one second of inactivity, which reduces power
consumption to less than 0.3 mA.
• After one minute of inactivity, power consumption drops further to less than 0.2 mA, and the
blue LED underneath the scroll wheel (2) turns off. To exit standby mode, move the mouse.
• After 30 minutes of inactivity, power consumption drops to less than 30 uA, and the blue LED
underneath the scroll wheel (2) turns off completely. To wake the mouse, press a button.
Maintenance and cleaning
• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could
damage the casing or even impair the functioning of the mouse.
• Before cleaning the mouse, turn it off using the on/off switch.
• Do not immerse the mouse in water.
• Use a dry, lint-free cloth to clean the mouse.
• To clean the sensor, blow on it briefly or clean it with a soft, clean brush.
• If the cursor doesn't move properly after you have used the mouse for a long period of time,
check whether the sensor on the bottom of the mouse is dirty.
• If so, remove any dust with a soft, clean brush.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this
product conforms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Select a language by clicking on a flag symbol and enter the product order number
in the search box. You can then download the EU declaration of conformity in PDF
format.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Power supply .....................................3.7 V 500 mAh lithium ion rechargeable battery
Charging current ................................500 mA
Current consumption .........................6 mA (active), <0.2 mA (standby), <30 μA (sleep mode)
Cable length
(USB 2.0 charging cable) ..................0.7 m
Working frequency .............................2.4 GHz
Range ................................................8 – 10 m
Sensitivity ..........................................800/1200/1600 dpi
Motion detector ..................................Optical sensor
System requirements ......................... Windows
Vista™ (32/64-bit), 7 (32/64-bit), 8 (32/64-bit),
8.1 (32/64-bit), 10 (32/64-bit), RT, Mac OS 10.6, 10.11
Operating conditions ..........................-5 to +40 °C, 20 – 90 % RH
Storage conditions .............................-5 to +40 °C, 20 – 90 % RH
Dimensions (W x H x D) ....................102 x 82 x 81 mm
Weight ...............................................110 g
XP (Home, Pro, with SP1, SP2, SP3) (32-bit),
®
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2016 by Conrad Electronic SE.
*1486136_v2_1016_02_DS_m_(1)_2L
